| Place Of Origin: | USA | Model: | EX3400-48T |
|---|---|---|---|
| Discription: | Poe Ethernet Switch | Keyword: | Fast Ethernet Switch |
| Product: | Managed Gigabit Switch | Warranty: | 1 Year |
| Package: | Original Packaging | MOQ: | 1pcs |
| High Light: | 48port Ethernet Light Switch,Tp Link Poe Ethernet Light Switch,Layer Managed Cisco Ethernet Switch |
||
EX3400 48T 48port network ethernet light switch network layer managed switch tp link poe
(poe ethernet switch fast ethernet switch managed gigabit switch)
poe ethernet switch EX3400-48T Overview
EX3400-48T is a Juniper EX3400 poe ethernet switch with 48-port 10/100/1000BASE-T, 4 x 1/10GbE SFP/SFP+, 2 x 40GbE QSFP+, redundant fans, front-to-back airflow, 1 AC PSU JPSU-150-AC-AFO included (optics sold separately). EX3400 Ethernet Switches are a cost-effective solution for today’s most demanding converged video enterprise access networks. The compact, fixed-configuration 1U devices offer levels of performance and management previously available only with high-end access switches.
| SKU | EX3400-48T |
| Ports | 48-port 10/100/1000BASE-T, 4 x 1/10GbE SFP/SFP+, 2 x 40GbE QSFP+ |
| Backplane speed | 160 Gbps |
| Throughput | 250 Mpps (wire speed) |
| Dimensions (W x H x D) | 17.4 x 1.7 x 13.8 in (43.7 x 4.4 x 35 cm) 1 rack unit |
EX3400-48T Specification |
|
| Description | EX3400 48-port 10/100/1000BASE-T, 4 x 1/10GbE SFP/SFP+, 2 x 40GbE QSFP+, redundant fans, front-to-back airflow, 1 AC PSU JPSU-150-AC-AFO included (optics sold separately) |
| Form factor | Fixed platform Virtual Chassis configuration consisting of up to 10 switches Junos Fusion Enterprise Satellite device |
| Dimensions (W x H x D) | 17.4 x 1.7 x 13.8 in (43.7 x 4.4 x 35 cm) 1 rack unit |
| Backplane speed | 160 Gbps |
| Data rate | 336 Gbps |
| Throughput | 250 Mpps (wire speed) |
| 40GBASE quad small form-factor pluggable plus transceiver (QSFP+) port densities | 2 |
| 100GBASE C form-factor pluggable transceiver (CFP) port densities | N/A |
| Resiliency | Redundant, field-replaceable power supplies Redundant trunk groups that provide port redundancy and simplify switch configuration |
| Operating system | Junos OS |
| Traffic monitoring | sFlow |
| Quality-of-service (QoS) queues/port | 8 unicast/4 multicast |
| IPv4 unicast/multicast routes | 36,000/4,000 |
| IPv6 unicast/multicast routes | 18,000/2,000 |
| Number of VLANs | 4,096 |
| ARP entries | 16,000 |
