| Place Of Origin: | USA | Model: | ASR1001X-2.5G-K9 |
|---|---|---|---|
| Key Word: | Network Switch 24 Port | Discription: | Optical Fiber Switch |
| Product: | Cisco Catalyst Switch | Shipping: | DHL FEDEX |
| Package: | Original Packaging | MOQ: | 1pcs |
| High Light: | Cisco Gigabit Wireless Router,24 Port Gigabit Wireless Router,ASR1001X-2.5G-K9 Ethernet Network Switch |
||
ASR1001X 2.5G K9 Cisco Ethernet Switch Gigabit Wireless Poe Network Switch 24 Port
(network switch 24 port optical fiber switch cisco catalyst switch)
The Cisco ASR1001X-2.5G-K9 Router is a 24 port poe switch 1-rack-unit (1RU) platform targeted towards the low to medium Enterprise and Managed Service Provider use cases. Its compact form factor has a built-in Route Processor, Embedded Services Processor (ESP) and Shared Port Adapter (SIP) Interface processor.
| Product Code | ASR1001X-2.5G-K9 |
| Rack Height | 1RU |
| System Bandwidth | 2.5G (default) / 5G, 10G, 20G (upgrade) |
| Router Processor (RP) | Quad-core 2.13Ghz processor |
| Build-in Gigabit Ethernet port | 6 x SFP ports, 2 x SFP+ ports |
| SIP and Ethernet line card | Integrated in chassis; not upgradable |
| Embedded hardware-based encryption | up to 8-Gbps crypto support throughput |
| Rack-mounting | 19-inch |
| DRAM Memory | 4 GB |
| Flash Memory | 8 GB |
| Shared port adapters | 1 SPA slot |
| External USB flash memory | 1-GB USB flash-memory support |
ASR1001X-2.5G-K9 Specifications |
|
|
Physical specifications Note: Depth applies to chassis edge-to-edge dimension and does not include protrusions such as card handles, power-supply handles, and cable management brackets. Refer to the applicable hardware installation guide for additional details. |
Height: 1.71 in. (43.43 mm) Width: 17.3 in. (439.42 mm) Depth: 18.17 in. (461.5 mm) Weight: ● 25 lb (11.35 kg) fully loaded Note: The Cisco ASR 1001-X Router has the route processor, ESP, and SIP integrated. |
| Default memory | 8-GB DRAM shared across route processor, ESP, and SIP |
| Number of SIPs or Ethernet line cards supported | Integrated in chassis |
| Shared port adapters | 1 single-height SPA slot |
| Ethernet port adapters | N/A |
| Cisco ASR 1000 Series ESP | Integrated in chassis |
| Route processor | Integrated in the chassis: Cisco ASR 1001-X Series Route Processor with Quad Core Processor |
| Redundancy | Software: Yes |
| Built-in Gigabit Ethernet ports | Yes: 6 Gigabit Ethernet Small Form-Factor Pluggable (SFP) ports |
| Built-in 10 Gigabit Ethernet port |
Yes: Two 10 Gigabit Ethernet Small Form-Factor Plus Pluggable (SFP+) ports Note:Built-in 10-GB ports cannot be reduced to 1-GB speed. |
| Network interface module | Yes |
| Cisco ASR 1000 Series | Cisco ASR 1001-X |
| ESP support |
Cisco ASR 1000 Series 2.5-Gbps ESP (default) Upgradable through a software-activated feature license to 5, 10, or 20 Gbps |
| ESP bandwidth | 2.5 to 20 Gbps |
| ESP memory | Share the same control memory on route processor |
| SIPs and Ethernet line cards | Integrated in chassis; not upgradable |
| Embedded hardware-based encryption | Yes: Up to 8-Gbps crypto support throughput |
| Minimum Cisco IOS XE Software release | Cisco IOS XE Software Release 3.12.0 |
| Rack-mounting | Yes: 19-inch |
| Wall-mounting | No |
| External USB flash memory | 1-GB USB flash-memory support |
| Redundant power supply |
Yes: Dual power supplies by default; option of either AC or DC power supply Note: A mix of one AC and one DC power supply is not supported. |
| Power input |
Worldwide ranging AC input range (85 to 264 VAC) Worldwide ranging DC (-40 to -72V; 48V nominal) |
| Power consumption |
● Maximum (DC): 242W ● Maximum (AC): 250W ● Maximum (out): 250W |
| Airflow | Front-to-back |
| Operating temperature (nominal) | 32 to 104°F (0 to 40°C) |
| Operating temperature (short-term) | 32 to 122°F (0 to 50°C) |
| Operating humidity (nominal) (relative humidity) | 10 to 85% |
| Operating humidity (short-term) | 5 to 90% |
| Storage temperature |
-40 to 150°F (-40 to 70°C) |
| Storage humidity (relative humidity) | 5 to 95% |
| Operating altitude | -500 to 10,000 feet (152 to 3048 meters) |
| Safety Standard |
UL60950-1 CSA C22.2 No. 60950-1-03 EN 60950-1 IEC 60950-1 AS/NZS 60950.1 |
