| Certification: | CE | Name: | C9200L-24P-4X-A |
|---|---|---|---|
| Model: | C9200L-24P-4X-A | Detail: | Catalyst 9200L 24-port PoE+ 4x10G Uplink Switch, Network Advantage |
| Availability: | In Stock | Condition: | New Factory Sealed |
| Warranty: | 1 Years | Place Of Origin:: | China |
| Software: | Network Essentials | Ports:: | 24 |
| High Light: | .4 Uplinks Cisco Poe Switch,Gigabit Ethernet Cisco Network Switches,24 Ports Cisco Ethernet Switches |
||
C9200L-24P-4X-A Specification |
|
| Downlinks total 10/100/1000 or PoE+ copper ports | 24 ports full PoE+ |
| Uplink configuration | 4x 10G fixed uplinks |
| Default primary AC power supply | PWR-C5-600WAC |
| Fans | Fixed redundant |
| Software | Network Advantage |
| Chassis Dimensions |
1.73 x 17.5 x 11.3 in 4.4 x 44.5 x 28.8 cm |
| Virtual Networks | 1 |
| Stacking bandwidth | 80 Gbps |
| Total number of MAC addresses | 16,000 |
| Total number of IPv4 routes (ARP plus learned routes) | 11,000 (8,000 direct routes and 3,000 indirect routes) |
| IPv4 routing entries | 3,000 |
| IPv6 routing entries | 1,500 |
| Multicast routing scale | 1,000 |
| QoS scale entries | 1,000 |
| ACL scale entries | 1,500 |
| Packet buffer per SKU | 6 MB buffers for 24- or 48-port Gigabit Ethernet models |
| Flexible NetFlow (FNF) entries | 16,000 flows on 24- and 48-port Gigabit Ethernet models |
| DRAM | 2 GB |
| Flash | 4 GB |
| VLAN IDs | 1024 |
| Total Switched Virtual Interfaces (SVIs) | 512 |
| Jumbo frames | 9198 bytes |
| Wireless bandwidth per switch | N/A |
| Switching capacity | 128 Gbps |
| Forwarding rate | 190.4 Mpps |
| Mean time between failures (hours) | 390,310 |
