Product Details:
|
| Model: | C9200L-24T-4G-E | Name: | Catalyst 9200L 24-port Data 4x1G Uplink Switch, Network Essentials |
|---|---|---|---|
| Detail: | C9200L-24T-4G-E - Cisco Switch Catalyst 9200 | Keywords: | C9200L-24T-4G-E Switch Port |
| Ports: | 4 X 10GE SFP+ | Downlinks Total 10/100/1000 Or PoE+ Copper Ports: | 24 Ports Data |
| Uplink Configuration: | X4x 1G Fixed Uplinks | Default Primary AC Power Supply: | PWR-C5-125WAC |
| High Light: | Catalyst 9200 24 Port Poe Switch,Fixed Uplinks 24 Port Poe Switch,Poe Cisco Catalyst Switch |
||
C9200L - 24T - 4G - E - Cisco Switch Catalyst 9200 24 port poe switch
C9200L-24T-4G-E is the Catalyst 9200L 24-port Data 4x1G uplink Switch, with Network Essentials software. Cisco® Catalyst® 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree, Catalyst 9200 Series switches offer simplicity without compromise – it is secure, always on, and IT simplified.
| Model | C9200L-24T-4G-E |
| Downlinks total 10/100/1000 or PoE+ copper ports | 24 ports data |
| Uplink configuration | 4x 1G fixed uplinks |
| Default primary AC power supply | PWR-C5-125WAC |
| Fans | Fixed redundant |
| Software | Network Essentials |
| Stacking bandwidth | 80 Gbps |
| DRAM | 2 GB |
| Flash | 4 GB |
| Switching capacity | 56 Gbps |
| Forwarding rate | 83.33 Mpps |
| Chassis Dimensions |
1.73 x 17.5 x 11.3 in 4.4 x 44.5 x 28.8 cm |
| Weight | 15.07 Kg |
C9200L-24T-4G-E Specification |
|
| Downlinks total 10/100/1000 or PoE+ copper ports | 24 ports data |
| Uplink configuration | 4x 1G fixed uplinks |
| Default primary AC power supply | PWR-C5-125WAC |
| Fans | Fixed redundant |
| Software | Network Essentials |
| Chassis Dimensions |
1.73 x 17.5 x 11.3 in 4.4 x 44.5 x 28.8 cm |
| Weight | 4.35 Kg |
| Virtual Networks | 1 |
| Stacking bandwidth | 80 Gbps |
| Total number of MAC addresses | 16,000 |
| Total number of IPv4 routes (ARP plus learned routes) | 11,000 (8,000 direct routes and 3,000 indirect routes) |
| IPv4 routing entries | 3,000 |
| IPv6 routing entries | 1,500 |
| Multicast routing scale | 1,000 |
| QoS scale entries | 1,000 |
| ACL scale entries | 1,500 |
| Packet buffer per SKU | 6 MB buffers for 24- or 48-port Gigabit Ethernet models |
| Flexible NetFlow (FNF) entries | 16,000 flows on 24- and 48-port Gigabit Ethernet models |
| DRAM | 2 GB |
| Flash | 4 GB |
| VLAN IDs | 1024 |
| Total Switched Virtual Interfaces (SVIs) | 512 |
| Jumbo frames | 9198 bytes |
| Wireless bandwidth per switch | N/A |
| Switching capacity | 56 Gbps |
| Forwarding rate | 83.33 Mpps |
| Mean time between failures (hours) | 531,030 |
