Product Details:
|
| Condition: | NIB And Used | Branch: | Cisco |
|---|---|---|---|
| Type: | Router Modules | Device Type: | Serial Adapter |
| Form Factor: | Plug-in Module | PN: | NIM-1CE1T1-PRI |
| High Light: | cisco router switch module,cisco service module |
||
Cisco® 4400 Series Integrated Services Router Network Interface Modules (ISRNIMs) provide highly reliable synchronous serial WAN connections for remote sites. These interfaces use well-known point-to-point WAN protocols such as High-Level Data Link Control (HDLC) and Point-to-Point Protocol (PPP) as well as Frame Relay, offering cost-effective virtualized WAN connections in both point-to-point and point-to-multipoint designs. You can mix and match NIMs to tailor cost-effective solutions for common networking solutions for low- and high-density WAN aggregation.
The Cisco Gigabit Ethernet High-Speed WAN Interface Card (HWIC) brings Gigabit Ethernet connectivity to Cisco Integrated Services Routers routers to accelerate applications such as Metro Ethernet access, inter-VLAN routing, and high-speed connectivity to LAN switches.The single-port Cisco Gigabit Ethernet HWIC provides Gigabit Ethernet optical and copper connectivity in a compact form factor for all Cisco Integrated Service Routers (ISRs).
| NIM-2T Specification | |
| General | |
| Device Type | Serial adapter |
| Form Factor | Plug-in module |
| Networking | |
| Ports | RS-232/449/530/V.35/X.21 x 2 |
| Connectivity Technology | Wired |
| Data Link Protocol | RS-232, RS-530, X.21, V.35, RS-449, RS-530A |
| Data Transfer Rate | 8 Mbps |
| Expansion / Connectivity | |
| Interfaces | 2 x RS-232/449/530/V.35/X.21 |
| Miscellaneous | |
| Compliant Standards | CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class A, EN50082-1, AS/NZS 60950-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, JATE, ICES-003 Class A, EN 61000-4-5, EN 61000-4-11, EN 61000-4-8, UL 60950-1, IEC 60950-1, EN 60950-1, FCC Part 15 A, CAN/CSA C22.2 No. 60950-1, VCCI Class A, EN 300386, CNS 13438 |
| Dimensions & Weight | |
| Width | 3.5 in |
| Depth | 7.2 in |
| Height | 1.3 in |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Synchronous support | Yes |
| Synchronous maximum speed (per port) | 8 Mbps |
| Serial protocols | EIA-232, EIA-449, EIA-530, EIA-530A, V.35, and X.21 |
| Telecomm post, telephone, and telegraph (PTT) | • TBR1 and 2 |
| • JATE digital | |
| Safety | • UL 60950-1 (United States) |
| • CAN/CSA 22.2, 60950-1 (Canada) | |
| • AS/NZS 60950-1 (Australia/New Zealand) | |
| • EN60950-1 (Europe) | |
| • IEC 60950-1 (International) | |
| Immunity | • EN300386 |
| • CISPR24 | |
| • EN55024 | |
| • EN50082-1 | |
| • 61000-4-2/3/4/5/6/8/11 | |
| Emissions | • FCC Part 15 Class A |
| • ICES-003 Class A | |
| • EN55022 Class A | |
| • CISPR22 Class A | |
| • AS/NZSCISPR22 Class A | |
| • VCCI Class A | |
| • EN 300386 | |
| • EN61000-3-2/3 | |
| • CNS13438 | |
| Physical specifications | • Singlewide NI, no slot restrictions |
| • Dimensions (H x W x D) 1.25 x 3.50 x 7.24 in. (3.18 x 8.89 x 18.39 cm) | |
| Environmental specifications | • Operating temperature: 32 to 104°F (0 to 40°C) |
| • Storage temperature: -4 to 149°F (-20 to 65°C) | |
| • Relative humidity: 10 to 90%, noncondensing | |
