Product Details:
|
| Warranty: | 1 Year | Brand: | CISCO |
|---|---|---|---|
| Number Of Ports: | 48 | Port Speed: | 1GbE/100Mbps |
| Port Type: | Pluggables | Wire Rate: | 1:1 |
| High Light: | optical ethernet switch,fiber optic network switch |
||
Cisco Catalyst WS-X4748-SFP-E line-card is designed for requiring line-rate capability for enterprise, mid-market and commercial core and distribution deployments. Integrated 48 SFP nonblocking ports with IEEE802.1AE Fiber Encryption and Cisco TrustSec capability in hardware, WS-X4748-SFP-E line-card delivers high-performance and secures user experience. This WS-X4748-SFP-E is similar with the WS-X4748-SFP-E=. The WS-X4748-SFP-E= is a spare one..
WS-X4748-SFP-E Specifications |
|
| Port Information | |
| Type | E-Series Gigabit Ethernet SFP Line Cards |
| Number of Ports | 48 |
| Port Speed | 1GbE/100Mbps |
| Port Type | Pluggables |
| Wire Rate | 1:1 |
| Feature | |
| Standards |
● Gigabit Ethernet: IEEE 802.3z, IEEE 802.3x, IEEE 802.3ab, IEEE 803.3at, IEEE 802.3af, IEEE 802.3az ● 1000BASE-X (GBIC), 1000BASE-SX, 1000BASE-LX/LH, 1000BASE-ZX, CWDM |
| EtherChannel Technology |
● Gigabit EtherChannel: All 1000 Mbps ports ● 10 Gigabit EtherChannel: All 10Gbps ports ● IEEE 802.3ad (Link Aggregation Control Protocol): All 1000 Mbps ports ● Port Aggregation Protocol (PagP): Yes ● Number of ports per tuple: 8 ● EtherChannel and IEEE 802.3ad technology across line cards: Yes |
| Physical Dimensions |
● Occupies one slot in the Cisco Catalyst 4500 Series platform ● Dimensions (H x W x D): 1.2 x 14.25 x 10.75 in. (3.0 x 36.2 x 27.3 cm) |
| Environmental Conditions |
● Operating temperature: 32° to 104°F (0° to 40°C) ● Storage temperature: -40° to 167°F (-40° to 75°C) ● Relative humidity: 10 to 90%, noncondensing ● Operating altitude: -60 to 3000m |
| Safety Conditions | Fiber optic lasers: Class 1 laser products |
| Safety Certifications |
● UL 1950 ● EN 60950 ● CSA-C22.2 no 950 ● IEC 950 ● IEC 60950-1, 2nd Ed. EN 60950-1, 2nd Ed. UL 60950-1, 2nd Ed. CAN/CSA-C22.2 No. 60950-1 2nd Ed.11 |
| Electromagnetic Emissions Certifications |
● FCC 15J Class A ● VCCI Class A ● CE Marking ● EN 55022 Class A ● EN 55024 Class A ● CISPR 22 Class A ● AS/NZ 3548 ● NEBS Level 3 (GR-1089-CORE, GR-63-CORE) ● ETSI ETS-300386-2 ● EN 50121-4 |
| ROHS Compliance | ROHS5 |
| Power and MTBF Information | |
| Max Rated Power (W) | 92 |
| Rated MTBF (Hours) | 876,100 |
