Product Details:
|
| Brand: | Cisco | Model: | WS-C3850-12XS-S |
|---|---|---|---|
| Ports: | 12 X 10/100/1000 10G SFP+ Optical Ports | DRAM: | 4 GB |
| Flash Memory: | 4 GB | ||
| High Light: | optical ethernet switch,poe ethernet switch |
||
Cisco WS-C3850-12XS-S Catalyst 3850 12 Port 10G Fiber Switch IP Base, with PWR-C1-350WAC AC Power
Overview
NEW Cisco Catalyst WS-C3850-12XS-S 3850 XS 12 Port SFP+ 10G Switch IP Base
WS-C3850-12XS-S switch provides 12 ports 10Gbps SFP+ connection with upgradeable IP base image and build in wireless controller provide fully convergence between wired and wireless on a single platform. It only supports 4 × 10 Gigabit Ethernet network module uplinks option.
Specifications:
| model info: | WS-C3850-12XS-S |
| enclosure type | Rack-mountable - 1U |
| Ports | 12 x SFP+ ports |
| Network management Interface | ● Ethernet management port: RJ-45 connectors, 4-pair Cat-5 UTP cabling ● Management console port: RJ-45-to-DB9 cable for PC connections |
| Available PoE Power | None |
| Switching Capacity | 320Gbps |
| Maximum stacking number | 9 |
| Stack Bandwidth | 480Gbps |
| Forwarding Performance | 227.28Mpps |
| FNF entries | 48,000 flows |
| Maximum VLANs IDs | 1,000 |
| MAC Address Table Size | 32K |
| CPU | Multicore CPU |
| RAM | 4 G |
| Flash Memory | 4 G |
| Wireless | |
| Number of AP per switch/stack | 100 |
| Number of wireless clients per switch/stack | 2000 |
| Total number of WLANs per switch | 64 |
| Wireless bandwidth per switch | up to 20Gbps |
| Supported Aironet AP series | 3600, 3500, 2600, 1600, 1260, 1140, 1040 |
| Expansion / Connectivity | |
| Console ports | USB (Type-B), Ethernet (RJ-45) |
| Expansion Slot(s) | 1 network module slot and 1 power redundant slot |
| Network Modules Selection | ● C3850-NM-4-1G: 4 x 1G uplinks network module ●C3850-NM-2-10G: 2 x 10G or 4 x 1G uplinks network module |
| Stacking cable | ●STACK-T1-50CM StackWise stacking cable with a 0.5 m length ●STACK-T1-1M StackWise stacking cable with a 1.0 m length ●STACK-T1-3M StackWise stacking cable with a 3.0 m length |
| Stack Power Cable (recommended) | ●CAB-SPWR-30CM stack power cable with a 30CM length ●CAB-SPWR-150CM stack power cable with a 150CM length |
| Power supply | PWR-C1-350WAC |
| Power Device | Power supply - redundant - plug-in module |
| Power Redundancy | optional |
| Voltage range (Auto) | 100V-240V |
| Power Consumption of standalone(in Watts) | 109.75 (Max) |
| Miscellaneous | |
| Width | 17.5 Inches (44.5 cm) |
| Depth | 17.7 Inches (45.0 cm) |
| Height | 1.75 Inches (4.45 cm) |
| Weight | 12.9 Pounds (5.8 Kg) |
