Cisco POE Switch WS-C3560X-24P-L Catalyst PoE Managed Gigabit Ethernet Network Switch 256 MB DRAM

Certification
China LonRise Equipment Co. Ltd. certification
China LonRise Equipment Co. Ltd. certification
Customer Reviews
It's good supplier with good service.

—— Mark Rejardest

LonRise it's goods supplier it's value business.

—— David Vike Moj

Very pleasant cooperation, valuable supplier, will continue to keep cooperation

—— Johnny Zarate

During the delivery the goods was damaged by the DHL, but LonRise arrange the new goods to us timely, really goods very appreciate for our supplier

—— Li Papageorge

Trustable supplier in China, Very happy to do business with Lonrise.

—— Rohit Verma

Good quality with good price, it's my first time to purchase equipment from China, Fast delivery, DHL 3 days to Mexico, Nice experience.

—— Sergio varela

I'm Online Chat Now

Cisco POE Switch WS-C3560X-24P-L Catalyst PoE Managed Gigabit Ethernet Network Switch 256 MB DRAM

Cisco POE Switch WS-C3560X-24P-L Catalyst PoE Managed Gigabit Ethernet Network Switch 256 MB DRAM
Cisco POE Switch WS-C3560X-24P-L Catalyst PoE Managed Gigabit Ethernet Network Switch 256 MB DRAM Cisco POE Switch WS-C3560X-24P-L Catalyst PoE Managed Gigabit Ethernet Network Switch 256 MB DRAM Cisco POE Switch WS-C3560X-24P-L Catalyst PoE Managed Gigabit Ethernet Network Switch 256 MB DRAM Cisco POE Switch WS-C3560X-24P-L Catalyst PoE Managed Gigabit Ethernet Network Switch 256 MB DRAM

Large Image :  Cisco POE Switch WS-C3560X-24P-L Catalyst PoE Managed Gigabit Ethernet Network Switch 256 MB DRAM

Product Details:
Place of Origin: USA
Brand Name: Cisco
Certification: CE
Model Number: WS-C3560X-24P-L
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: Negotiable
Packaging Details: NEW IN BOX
Delivery Time: 1~2 days
Payment Terms: T/T, Western Union, Paypal, Alipay, Wechat
Supply Ability: 30 units per month

Cisco POE Switch WS-C3560X-24P-L Catalyst PoE Managed Gigabit Ethernet Network Switch 256 MB DRAM

Description
Brand: Cisco Model: WS-C3560X-24P-L
Ports: 24 X 10/100/1000 Ethernet Ports DRAM: 256 MB
Flash Memory: 64 MB
High Light:

optical ethernet switch

,

poe ethernet switch

Cisco WS-C3560X-24P-L Catalyst 24 Port Managed PoE Gigabit Ethernet Switch


Overview


Cisco Catalyst WS-C3560X-24P-L is 24 Gigabit Ethernet POE+ ports standalone switch in LAN base feature set with no stacking option. Four optional network modules and license-base software feature provide flexibility, scalability and feature extensibility in order to reduce the cost of development of business needs. WS-C3560X-24P-L support IEEE802.3at standard to allocate up to 30W power on each port in total 435W POE budget to power up IP phones, wireless and video; customers can specify the power setting on individual port in command line setting. LAN base feature set offers up to 255-Vlans and comprehensive layer 2 feature with static routing and SVI interface supporting.

WS-C3560X-24P-L is designed for enterprise access layer switching; however, customers can transparently upgrade the software feature to by purchasing either IP base license or IP services license to activate layer 3 capability, 1005 VLans supporting. WS-C3560X-24P-L comes with one default power supply module, customers can purchase additional power supply insert into power supply bay 2 in order to power redundancy.




 Cisco POE Switch WS-C3560X-24P-L Catalyst PoE Managed Gigabit Ethernet Network Switch 256 MB DRAM 0

Specifications:

WS-C3560X-24P-L data sheet
Manufacturer Cisco Systems, Inc
Manufacturer Part Number WS-C3560X-24P-L
Product Type Switch - 24 ports - Managed
Form Factor Rack mountable - 1U
Switch Ports 24 x 10/100/1000 Ethernet Ports Ethernet Ports
Power Over Ethernet (PoE) Yes
Performance Switching capacity : 160 Gbps
Remote Management Protocol SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, FTP, TFTP, SSH, CLI
Authentication Method Kerberos, Secure Shell (SSH), RADIUS, TACACS+
Features Hot swap module replacement, Layer 2 switching, dynamic IP address assignment , DHCP support, power over Ethernet (PoE), auto-negotiation, ARP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, traffic shaping, Broadcast Storm Control, High Availability, Multicast Storm Control, Unicast Storm Control, Rapid Spanning Tree Protocol (RSTP) support, DHCP snooping, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), PoE+, Per-VLAN Spanning Tree Plus (PVST+)
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at
DRAM Memory 256 MB
Flash Memory 64 MB Flash
Status Indicators Port status, link activity, port transmission speed, port duplex mode, power, system
Connectivity Slots
Interfaces 24 x 10Base-T/100Base-TX/1000Base-T - RJ-45 - PoE
USB : 1 x 4 PIN USB Type A
1 x console - mini-USB Type B - management
1 x RS-232 - RJ-45 - management
1 x 10Base-T/100Base-TX - RJ-45 - management
Expansion Slots Total (Free) 1 ( 1 ) x Expansion Slot
Power Supply
Power Device Power supply - redundant - plug-in module
Installed Qty 1 (installed) / 2 (max)
Power Redundancy Optional
Power Redundancy Scheme 1+1 (with optional power supply)
Voltage Required AC 120/230 V ( 50/60 Hz )
Features Redundant Power System (RPS) connector
Dimensions / Weight / Miscellaneous
Width 44.5 cm
Depth 46 cm
Height 4.5 cm
Weight 7.1 kg
Rack Mounting Kit Optional
MTBF 181,370 hour(s)
Compliant Standards CE, TUV GS, CISPR 22 Class A, GOST, cUL, NOM, VCCI Class A ITE, EN55022 Class A, CB, AS/NZS 60950-1, AS/NZ 3548 Class A, CCC, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, KCC, FCC Part 15 A, CSA C22.2 No. 60950-1
System Software
Software Included Cisco IOS LAN Base


Other related products:


WS-C3560X-24T-L
WS-C3560X-24T-S
WS-C3560X-24T-E
WS-C3560X-24P-L
WS-C3560X-24P-S
WS-C3560X-24P-E
WS-C3560X-48T-L
WS-C3560X-48T-S
WS-C3560X-48T-E
WS-C3560X-48P-L
WS-C3560X-48P-S
WS-C3560X-48P-E
WS-C3560X-48PF-L
WS-C3560X-48PF-S
WS-C3560X-48PF-E
WS-C3560G-48TS-E
WS-C3560G-48TS-S
WS-C3560G-24TS-S
WS-C3560G-24TS-E
WS-C3560V2-24TS-S
WS-C3560V2-48PS-S
WS-C3560V2-24PS-S
WS-C3560G-48PS-S
WS-C3560G-24PS-S


If you have any questions about cisco poducts or want to know more the other cisco products, please do not hesitate to contact with Dannis Hu.


Skype: lonrisesales02
Email: dannis(at)lonriseeqt.com
Tel: 86 13601984814
