WS-C3750X-24P-S Catalyst 3750X 24 Port Poe Switch High Speed C3KX-NM-1G

WS-C3750X-24P-S Catalyst 3750X 24 Port Poe Switch High Speed C3KX-NM-1G
WS-C3750X-24P-S Catalyst 3750X 24 Port Poe Switch High Speed C3KX-NM-1G WS-C3750X-24P-S Catalyst 3750X 24 Port Poe Switch High Speed C3KX-NM-1G WS-C3750X-24P-S Catalyst 3750X 24 Port Poe Switch High Speed C3KX-NM-1G WS-C3750X-24P-S Catalyst 3750X 24 Port Poe Switch High Speed C3KX-NM-1G

Large Image :  WS-C3750X-24P-S Catalyst 3750X 24 Port Poe Switch High Speed C3KX-NM-1G

Product Details:
Place of Origin: USA
Brand Name: Cisco
Certification: CE
Model Number: WS-C3750X-24P-S
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: Negotiable
Packaging Details: NEW IN BOX
Delivery Time: 1~2 days
Payment Terms: T/T, Western Union, Paypal, Alipay, Wechat
Supply Ability: 30 units per month

WS-C3750X-24P-S Catalyst 3750X 24 Port Poe Switch High Speed C3KX-NM-1G

Description
Brand: Cisco Model: WS-C3750X-24P-S
Ports: 24 X 10/100/1000 Ethernet Ports DRAM: 256 MB
Flash Memory: 128 MB
High Light:

optical ethernet switch

,

fiber optic network switch

Cisco WS-C3750X-24P-S Catalyst 3750X 24 Port Poe Switch

Overview

Cisco Catalyst 3750-X Series Switch WS-C3750X-24P-S is an enterprise-class lines of stackable and standalone switches, respectively. Catalyst 3750-X switches provide high availability, scalability, security, energy efficiency, and ease of operation with innovative features such as Cisco StackPower, IEEE 802.3at Power over Ethernet Plus (PoE+) configurations, optional network modules, redundant power supplies, and Media Access Control Security (MACsec) features. Cisco Catalyst 3750-X Series with StackWise Plus technology provides scalability, ease of management and investment protection for the evolving business needs. The Cisco Catalyst 3750-X switches enhance productivity by enabling applications such as IP telephony, wireless, and video for borderless network experience.
 WS-C3750X-24P-S Catalyst 3750X 24 Port Poe Switch High Speed C3KX-NM-1G 0


Specifications:



WS-C3750X-24P-S data sheet
Manufacturer Cisco Systems, Inc
Manufacturer Part Number WS-C3750X-24P-S
Product Type Switch - 24 ports - L3 - Managed - stackable
Form Factor Fixed, Rack Mountable 1U, Stackable/Clustering
Switch Port density - Uplinks 24 x 10/100/1000 Ethernet Ports
Power Over Ethernet (PoE) Yes
Max Number of Stacks 9
Routing Protocol RIP-1, RIP-2, HSRP, static IP routing, RIPng
Remote Management Protocol SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, TFTP, SSH, CLI
Authentication Method Kerberos, Secure Shell (SSH), RADIUS, TACACS+
Features Hot swap module replacement, Layer 3 switching, Layer 2 switching, dynamic IP address assignment , DHCP support, power over Ethernet (PoE), auto-negotiation, ARP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, traffic shaping, Broadcast Storm Control, High Availability, Multicast Storm Control, Unicast Storm Control, Rapid Spanning Tree Protocol (RSTP) support, DHCP snooping, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), PoE+, Per-VLAN Spanning Tree Plus (PVST+), EIGRP Stub Routing
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ae, IEEE 802.3at
DRAM Memory 256 MB
Flash Memory 128 MB Flash
LED Status Lights Indicators Port status, link activity, port transmission speed, port duplex mode, power, system
Connectivity / Expansion Slots
Interfaces 24 x 10Base-T/100Base-TX/1000Base-T - RJ-45 - PoE
USB : 1 x 4 PIN USB Type A
1 x console - mini-USB Type B - management
1 x RS-232 - RJ-45 - management
1 x 10Base-T/100Base-TX - RJ-45 - management
Network stack device : 2 x
Expansion Slot(s) 1 (total) / 1 (free) x Expansion Slot
Power Supply Specifications
Power Device Power supply - redundant - plug-in module
Installed Qty 1 (installed) / 2 (max)
Power Redundancy Optional
Power Redundancy Scheme 1+1 (with optional power supply)
Voltage Required AC 120/230 V ( 50/60 Hz )
Features Redundant Power System (RPS) connector
Dimensions / Weight / Miscellaneous
Width 44.5 cm
Depth 46 cm
Height 4.5 cm
Weight 7.2 kg
Rack Mounting Kit Optional
MTBF 167,198 hour(s)
Compliant Standards CE, TUV GS, CISPR 22 Class A, GOST, cUL, NOM, VCCI Class A ITE, EN55022 Class A, CB, AS/NZS 60950-1, AS/NZ 3548 Class A, CCC, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, KCC, FCC Part 15 A, CSA C22.2 No. 60950-1
System Software
Software Included Cisco IOS IP Base
