Quick Specs
Feature |
Specification |
Brand |
Cisco |
Model |
CSF1210CE-TD-K9 |
Product Series |
Cisco Secure Firewall 1200 Series |
Appliance Model |
Secure Firewall 1210CE |
Software |
Threat Defense (NGFW) |
Form Factor |
Compact desktop appliance |
Network Interfaces |
8 × 1GbE RJ45 |
Management Interface |
1 × 1GbE RJ45 |
Console Interfaces |
RJ45 serial, USB Type-C |
USB Interface |
1 × USB Type-A 3.0 |
Firewall Throughput |
Up to 6.5 Gbps |
Threat Defense Throughput |
Up to 6.0 Gbps |
IPS Throughput |
Up to 6.0 Gbps |
Typical Power Consumption |
32 W |
Maximum Power Consumption |
40 W |
Specifications are based on Cisco's published 1210CE documentation. Throughput varies by traffic profile and enabled security services.
Technical Specifications
Parameter |
Details |
Product Part Number |
CSF1210CE-TD-K9 |
Product Description |
Cisco Secure Firewall 1210CE Compact Appliance with Threat Defense Software |
Security Platform |
Next-Generation Firewall (NGFW) |
Firewall Throughput |
6.5 Gbps |
Threat Defense Throughput |
6.0 Gbps |
IPS Throughput |
6.0 Gbps |
TLS Throughput |
1.0 Gbps |
Fixed Network Ports |
8 × 10/100/1000BASE-T Ethernet |
SFP/SFP+ Ports |
Not supported on the 1210CE |
PoE Support |
No |
Management Port |
1 × 1GbE RJ45 |
Console Connectivity |
RJ45 serial and USB Type-C |
USB Port |
1 × USB Type-A 3.0 |
Internal Storage |
480 GB M.2 NVMe |
Dimensions (H × W × D) |
Approx. 2.82 × 27.43 × 17.22 cm, excluding rubber feet |
Chassis Weight |
Approx. 1.38 kg |
Power Supply |
External 12 V DC, 66 W rated adapter |
Typical Power Consumption |
32 W |
Maximum Power Consumption |
40 W |
Operating Temperature |
0°C to 40°C |
Mounting Options |
Desktop; optional wall-mount or rack-shelf kit |
Hardware details are drawn from Cisco's official data sheet and installation guide. Confirm the supplied power adapter, software entitlement, and accessory configuration with the seller before ordering.
FAQ
Q1: What is the Cisco CSF1210CE-TD-K9 used for?
The CSF1210CE-TD-K9 is a compact next-generation firewall appliance designed for branch offices, smaller enterprise networks, and distributed business environments. It provides Gigabit Ethernet connectivity and supports Cisco Threat Defense software.
Q2: What is the difference between CSF1210CE-TD-K9 and CSF1210CE-ASA-K9?
The main difference is the software configuration.
Comparison |
CSF1210CE-TD-K9 |
CSF1210CE-ASA-K9 |
Hardware platform |
Secure Firewall 1210CE |
Secure Firewall 1210CE |
Software |
Threat Defense |
Adaptive Security Appliance (ASA) |
Primary consideration |
NGFW deployment |
ASA-based firewall deployment |
Best choice depends on |
Required threat defense features and licensing |
Existing ASA configuration and operational requirements |
Confirm feature availability and licensing requirements for the specific software release before purchasing.
Q3: How does the 1210CE compare with the Cisco Secure Firewall 1220CX?
The 1210CE offers eight 1GbE RJ45 network ports and is suitable for compact copper-based deployments. The 1220CX adds two 1/10Gbps SFP+ network interfaces and provides higher published firewall throughput of up to 9.0 Gbps.
Choose the 1210CE for basic Gigabit Ethernet connectivity and the 1220CX when faster optical or direct-attach network connections are required. Check transceiver compatibility and licensing before selecting a model.
Q4: Does the CSF1210CE-TD-K9 support PoE?
No. The 1210CE does not provide PoE output. If you need to power compatible access points, phones, or other devices directly from the firewall, consider the Cisco CSF1210CP-TD-K9, which supports PoE on four Ethernet ports.
Q5: What should I check before ordering?
Verify the following details with your supplier:
Exact part number: CSF1210CE-TD-K9.
Hardware condition: new, refurbished, or used.
Included power adapter and accessories.
Threat Defense software entitlement and subscription requirements.
Shipping availability, lead time, and applicable warranty terms.
Compatibility with your required network design.
Q6: What after-sales support should a supplier provide?
A professional networking equipment supplier should be able to assist with model verification, pre-shipment checks, product configuration information, and troubleshooting guidance within the agreed service scope.
Before placing an order, request written confirmation of the warranty period, return or replacement policy, technical support availability, and handling procedures for defective equipment. Software subscriptions and manufacturer support eligibility should be verified separately.
Q7: Can I request a quotation for the Cisco CSF1210CE-TD-K9?
Yes. When requesting a quotation, specify the quantity, destination country, preferred equipment condition, and whether software subscriptions or additional accessories are required. This helps the supplier prepare an accurate quotation and shipping estimate.
