Huawei CloudEngine S5755-H24UM4Y2CZ 24-Port Multi-GE PoE++ Switch with 100G Uplink for Enterprise Campus Networks

Large Image : Huawei CloudEngine S5755-H24UM4Y2CZ 24-Port Multi-GE PoE++ Switch with 100G Uplink for Enterprise Campus Networks

Product Details:

Place of Origin:	CHINA
Brand Name:	Huawei
Certification:	CE
Model Number:	S5755-H24UM4Y2CZ

Payment & Shipping Terms:

Minimum Order Quantity:	1
Delivery Time:	2-3 days
Payment Terms:	T/T

Contact Now

Huawei CloudEngine S5755-H24UM4Y2CZ 24-Port Multi-GE PoE++ Switch with 100G Uplink for Enterprise Campus Networks

Description

Product Name:	Huawei Network Switches	Part Number:	S5755-H24UM4Y2CZ
Payment:	TT/Paypal	Shipment:	DHL
Condition:	NEW	Lead Time:	2-3 Days
Warranty:	1 Year	Keywords:	S5755-H24UM4Y2CZ
Highlight:	Huawei CloudEngine 24-port PoE++ switch , enterprise network switch with 100G uplink , multi-GE PoE switch with warranty

Huawei S5755-H24UM4Y2CZ Overview

The Huawei CloudEngine S5755-H24UM4Y2CZ is a high-quality multi-gigabit access switch designed for enterprise campus networks. It features 24 flexible downlink ports supporting rates from 10M to 10G, and high-speed uplink ports (4 × 25GE + 2 × 100GE) for seamless expansion. With 90W PoE++ and N+1 power redundancy, it delivers reliable power supply and uninterrupted operation for IP phones, wireless APs, and security cameras.

Figure 1 shows the front panel of S5755-H24UM4Y2CZ.

Quick Specs

Item	Spec
Model	CloudEngine S5755-H24UM4Y2CZ
Downlink Ports	24 × 10/100/1000M/2.5/5/10G Base-T
Uplink Ports	4 × 1/10/25GE SFP28, 2 × 40/100GE QSFP28
PoE	90W PoE++
Switching Capacity	1.48 Tbps / 2.4 Tbps
Packet Forwarding	490 Mpps
Power Supply	N+1 backup
Expansion	1 × slot

Optional Add-ons

Model	Description
SFP-10G-SR	10GBASE-SR SFP+ Transceiver
QSFP-100G-LR4	100GBASE-LR4 QSFP28 Transceiver
LS-AC-600W	600W AC Power Supply

Huawei S5755-H24UM4Y2CZ Specification

Parameter	Specification
Model	Huawei CloudEngine S5755-H24UM4Y2CZ
Fixed Ports	24 × 10/100/1000M/2.5G/5G/10G Base-T PoE++ ports 4 × 1/10/25GE SFP28 ports 2 × 40/100GE QSFP28 ports
Expansion Slot	1 × dedicated expansion slot
Switching Capacity	1.48 Tbps (device), 2.4 Tbps (system)
Packet Forwarding Rate	490 Mpps
PoE Standard	IEEE 802.3af/at/bt, PoE++ up to 90W per port
Layer 3 Features	Static routing, RIP, OSPF, IS-IS, BGP, VXLAN, BGP-EVPN
Security Features	MACsec, 802.1X authentication, ACL, CPU protection
Power Supply Mode	Hot-swappable modular, supports N+1 redundancy
Operating Temperature	-5°C to +50°C
Mounting	19-inch standard rack-mountable
Management	SNMP, CLI, Web GUI, NETCONF, YANG
Application Scenario	Enterprise campus access & aggregation, high-density PoE deployment
