TS-OP-318H-01C/800G OSFP 2*FR4 Transceiver Dual LC Port | High-Speed Optical Module

Large Image : TS-OP-318H-01C/800G OSFP 2*FR4 Transceiver Dual LC Port | High-Speed Optical Module

Product Details:

Place of Origin:	China
Brand Name:	HUAWEI
Certification:	CE
Model Number:	800G OSFP 2*FR4 Dual LC

Payment & Shipping Terms:

Minimum Order Quantity:	1
Delivery Time:	2-3 days
Payment Terms:	T/T

Contact Now

TS-OP-318H-01C/800G OSFP 2*FR4 Transceiver Dual LC Port | High-Speed Optical Module

Description

Product Name:	SFP Optical Transceiver	Part Number:	800G OSFP 2*FR4 Dual LC
Shipment:	DHL	Condition:	New
Lead Time:	2-3 Days	Warranty:	1 Year
Keywords:	800G OSFP 2*FR4 Dual LC
Highlight:	OSFP 800G optical transceiver , dual LC port optical module , high-speed SFP transceiver

Product Overview

The TS-OP-318H-01C is a premium 800Gbps OSFP (Octal Small Form-factor Pluggable) optical transceiver engineered for hyperscale data centers, cloud computing, and AI/ML clusters. Utilizing a sophisticated 2*FR4 architecture, this module delivers 800G aggregate bandwidth via 8x100G PAM4 electrical lanes, multiplexed into two independent 400G FR4 optical channels.

Key Differentiation: The Dual LC port design is a strategic choice for operators looking to upgrade to 800G while maintaining existing LC duplex single-mode fiber infrastructure, avoiding the high cost and complexity of MPO/MTP conversion.

Figure 1 shows the front panel of 800G OSFP 2*FR4 Dual LC.

Technical Specifications

Parameter	Specification Detail
Form Factor	OSFP (Octal Small Form-factor Pluggable)
Data Rate	800Gbps (Dual 400G FR4 Engines)
Optical Wavelength	CWDM4 Grid (1271nm, 1291nm, 1311nm, 1331nm)
Connector Interface	Dual LC (Duplex LC Connector)
Transmission Distance	Up to 2km over G.652 Single-Mode Fiber (SMF)
Power Consumption	Optimized Low Power (<16W typical)
Diagnostics	Real-time Digital Diagnostic Monitoring (DDM/DOM)

Strategic Comparison: 2*FR4 vs. DR8 Solution

Choosing the right 800G module is critical for TCO (Total Cost of Ownership). Below is why the 2*FR4 model is often preferred for long-reach data center applications:

Feature	800G OSFP 2*FR4 (TS-OP-318H-01C)	800G OSFP DR8
Cabling Infrastructure	Standard LC Duplex Patch Cords	Complex MPO-16 / MTP-16
Fiber Core Usage	4 Cores (Highly Efficient)	16 Cores (Dense/Expensive)
Maximum Reach	2,000 Meters (2km)	500 Meters
Upgrade Path	Reuse existing 100G/400G LC fiber	Requires complete recabling

Frequently Asked Questions (FAQ)

Q: Why choose the 2*FR4 design for my 800G upgrade?: A: The 2*FR4 design uses CWDM technology to transmit 400G over a single pair of fibers, duplicated within one module. This offers a 2km reach—four times that of DR8—and drastically reduces fiber congestion in your cable trays.
Q: Is the TS-OP-318H-01C compatible with Cisco Catalyst and Nexus switches?: A: Absolutely. Our modules are coded and hardware-verified for seamless operation with Cisco, Arista, NVIDIA (Mellanox), and Juniper high-speed switching platforms.
Q: What support do you offer for after-sales and warranty?: A: We provide a comprehensive 1-year warranty and lifetime technical support. Every unit is tested in-house on actual switches before shipment to ensure 100% reliability.
Q: Does this module support DDM functions?: A: Yes, it provides full DDM support for monitoring temperature, laser bias current, and transmit/receive optical power, enabling proactive network maintenance.
