Optical Transceiver 40GBase-iSR4 Optical Transceiver QSFP+ 40G Multi-mode QSFP-40G-iSR4

Optical Transceiver  40GBase-iSR4 Optical Transceiver QSFP+ 40G Multi-mode QSFP-40G-iSR4
Optical Transceiver  40GBase-iSR4 Optical Transceiver QSFP+ 40G Multi-mode QSFP-40G-iSR4 Optical Transceiver  40GBase-iSR4 Optical Transceiver QSFP+ 40G Multi-mode QSFP-40G-iSR4

Large Image :  Optical Transceiver 40GBase-iSR4 Optical Transceiver QSFP+ 40G Multi-mode QSFP-40G-iSR4

Product Details:
Place of Origin: USA
Brand Name: HUAWEI
Certification: CE
Model Number: QSFP-40G-iSR4
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $200-$235
Delivery Time: 1-2days
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: 500 per week

Optical Transceiver 40GBase-iSR4 Optical Transceiver QSFP+ 40G Multi-mode QSFP-40G-iSR4

Description
Condition: Original New Model: QSFP-40G-iSR4
Optical Fiber Type: MMF Form Factor: SFP+
Max Data Rate: 40Gbps Wavelength: 850nm
Optical Components: VCSEL 850nm Connector Type: LC
Part Number: 02310MHR
Highlight:

40GBase-iSR4 QSFP+ transceiver

,

QSFP-40G-iSR4 multimode module

,

40G optical transceiver with warranty



Huawei QSFP-40G-iSR4 Overview



Huawei QSFP-40G-iSR4 Compatible 40GBASE-SR4/4x10GBASE-SR QSFP+ Transceiver (MMF, 850nm, 150m, MTP/MPO).

Quick Specs

Figure 1 shows the appearance of QSFP-40G-iSR4.

Optical Transceiver  40GBase-iSR4 Optical Transceiver QSFP+ 40G Multi-mode QSFP-40G-iSR4 6

Table 1 shows the Quick Specs.

Product Code QSFP-40G-iSR4
Part Number 02310MHR
Description 40GBase-iSR4 Optical Transceiver,QSFP+,40G,Multi-mode (850nm,0.15km,MPO)(Connect to four SFP+ Optical Transceiver)
Form Type QSFP+
Wavelength 850nm
Interface MTP/MPO
Cable Type MMF
CDR Support Yes
Commercial Temperature Range 0 to 70°C (32 to 158°F)
Max Data Rate 40Gbps
Max Cable Distance* 150m
Optical Components VCSEL 850nm
DOM Support NO
Protocols 40G Ethernet, Infiniband QDR, SATA/SAS3, IEEE 802.3ba

* Minimum cabling distance is 0.5 meters for -SR4 and -CSR4 modules.
Considered an engineered link with maximum 1 decibel loss budget.

Compare to Similar Items

Table 2 shows the comparison of QSFP-40G-ER4, QSFP-40G-iSR4 and QSFP-40G-LR4.

Product Code QSFP-40G-ER4 QSFP-40G-iSR4 CFP-40G-LR4
Part Number 02311BKT 02310MHR 02310MHS
Description 40GBase-ER4 Optical Transceiver,QSFP+,40G,Single-mode Module (1310nm,40km,LC) 40GBase-iSR4 Optical Transceiver,QSFP+,40G,Multi-mode (850nm,0.15km,MPO)(Connect to four SFP+ Optical Transceiver) 40GBase-LR4 Optical Transceiver,QSFP+,40GE,Single-mode Module(1310nm,10km,LC)
Form Type QSFP+ QSFP+ QSFP+
Wavelength 1310nm 850nm 1310nm
Max Data Rate 44.6Gbps 40Gbps 44.6Gbps
Max Cable Distance* 40km 150m 10km




Huawei QSFP-40G-iSR4 Specification



40GBase-iSR4 Optical Transceiver,QSFP+,40G,Multi-mode (850nm,0.15km,MPO)(Connect to four SFP+ Optical Transceiver)

Optical Transceiver  40GBase-iSR4 Optical Transceiver QSFP+ 40G Multi-mode QSFP-40G-iSR4 7
Optical Transceiver  40GBase-iSR4 Optical Transceiver QSFP+ 40G Multi-mode QSFP-40G-iSR4 8



Optical Transceiver  40GBase-iSR4 Optical Transceiver QSFP+ 40G Multi-mode QSFP-40G-iSR4 9

Optical Transceiver  40GBase-iSR4 Optical Transceiver QSFP+ 40G Multi-mode QSFP-40G-iSR4 10

Optical Transceiver  40GBase-iSR4 Optical Transceiver QSFP+ 40G Multi-mode QSFP-40G-iSR4 11

Optical Transceiver  40GBase-iSR4 Optical Transceiver QSFP+ 40G Multi-mode QSFP-40G-iSR4 12
