Product Details:
|
| Model: | CE5855-48T4S2Q-EI-F | Fixed Interfaces: | 48*10/100/1000BASE-T & 4*10GE SFP & 2*40GE QSFP+ |
|---|---|---|---|
| Switching Capacity: | 336 Gbit/s | Forwarding Rate: | 252 Mpps |
| Power Module Type: | Pluggable AC Or DC Power Module, 1+1 Backup Supported | Rated Voltage Range: | 100 V AC To 240 V AC, 50/60 Hz -48 V DC To -60 V DC |
| Maximum Power Consumption: | 103W | Dimensions: | 442 Mm X 420 Mm X 43.6 Mm |
| Weight: | 8.4 Kg | Condition: | New |
| Warranty: | 1 Year |
Huawei CE5855-48T4S2Q-EI provides 48 * GE line-speed ports plus 4 * 10 GE and 2 * 40G upstream ports for stacking up to 16 switches. 10 GE and 40G ports enable creation of a non-blocking stack that can extend across geographical distances between data centers. Using the Huawei VRP8 software platform, CE5800 switches support Transparent Interconnection of Lots of Links (TRILL) and have a high stacking capability (up to 16-member switches in a stack system). In addition, the airflow direction (front-to-back or back-to-front) can be changed. CE5800 switches can work with CE12800 switches to build an elastic, virtualized, high-quality fabric that meets the requirements of cloud-computing data centers. CE5800 switches provide high-density GE access to help enterprises build a scalable data center network platform for cloud computing. They can also be used as aggregation or access switches for enterprise campus networks.
Table 3 shows the comparison of CE5855-48T4S2Q-EI-F, CE5850-HI-B-B00 and CE5855-24T4S2Q-EI-B.
|
Product Code |
|||
|
Software Version |
V100R005C10 and later |
V100R003C00 and later |
V100R005C10 and later |
|
Fixed GE interfaces |
48*10/100/1000BASE-T |
48*10/100/1000BASE-T |
24*10/100/1000BASE-T |
|
Fixed 10GE interfaces |
4*10GE SFP+ |
4*10GE SFP+ |
4*10GE SFP+ |
|
Fixed 40GE interfaces |
2*40GE QSFP+ A 40GE interface can be split into four 10GE interfaces. |
2*40GE QSFP+ |
2*40GE QSFP+ A 40GE interface can be split into four 10GE interfaces. |
|
Fixed 100GE interfaces |
None |
None |
None |
|
Base-T Ports |
48 |
48 |
24 |
|
SFP+ Ports |
4 |
4 |
4 |
|
QSFP+ Ports |
2 |
2 |
2 |
|
Switching Capacity |
336 Gbit/s |
336 Gbit/s |
288 Gbit/s |
|
Forwarding Rate |
252 Mpps |
252 Mpps |
215 Mpps |
|
Maximum power consumption |
103W |
131W |
75W |
|
Product Code |
|
|
Software Version |
V100R005C10 and later |
|
Fixed GE interfaces |
48*10/100/1000BASE-T |
|
Fixed 10GE interfaces |
4*10GE SFP+ |
|
Fixed 40GE interfaces |
2*40GE QSFP+ A 40GE interface can be split into four 10GE interfaces. |
|
Fixed 100GE interfaces |
None |
|
Base-T Ports |
48 |
|
SFP+ Ports |
4 |
|
QSFP+ Ports |
2 |
|
Switching Capacity |
336 Gbit/s |
|
Forwarding Rate |
252 Mpps |
|
Power module type |
Pluggable AC or DC power module, 1+1 backup supported |
|
Rated voltage range |
100 V AC to 240 V AC, 50/60 Hz -48 V DC to -60 V DC |
|
Maximum power consumption |
103W |
|
Airflow |
Front-to-back or back-to-front, depending on the fan modules and power modules used in the chassis |
|
Dimensions (W x D x H) |
442 mm x 420 mm x 43.6 mm |
|
Weight (fully loaded) |
8.4 kg (18.5 lb) |
