Product Details:
|
| Name: | S1730S L24T A | Model: | S1730S L24T A Switch |
|---|---|---|---|
| Connector Type: | LC/PC | Warrranty: | 1 Year |
| Shipping: | DHL&FeDex | Ports: | 24 Ethernet 10 100 1000BASE T Ports |
| PoE: | Not Support | Dimensions (H X W X D): | ● Basic Dimensions (excluding The Parts Protruding From The Body): 43.6 Mm X 250 Mm X 180 Mm (1.72 In. X 9.84 In. X 7.09 In.) ● Maximum Dimensions (the Depth Is The Distance From Ports On The Front Panel To The Parts Protruding From The Rear Panel): 43.6 M |
| Payment: | TT/LC | ||
| Highlight: | AC power supply Huawei S1730 Switches,10100 1000BASE T Huawei S1730 Switches,24 Ethernet Huawei S1730 Switches |
||
Huawei S1730S-L24T-A is one of the Huawei S1730 unmanaged switches, with 24 Ethernet 10/100/1000BASE-T ports, and AC power supply. The S1700 unmanaged switch is deployed at the access layer of an enterprise network to deliver cost-effective packet switching capability. It provides high quality data transmission for enterprises. The S1700 unmanaged switch helps enterprises construct reliable networks that have high scalability.
Table 1 shows the quick spec.
| Part Number | S1730S-L24T-A |
| Ports | 24 Ethernet 10/100/1000BASE-T ports |
| PoE | Not Support |
| Dimensions (H x W x D) |
|
The S1700 unmanaged switch provides these features:
Flexible Networking Capability
The S1700 unmanaged switch provides 10/100/1000BASE-T, 1000BASE-X, and 10GBASE-X ports. The S1700 unmanaged switch provides swappable Small Form-Factor Pluggable (SFP) optical modules for GE optical fiber connections. The S1700 unmanaged switch provides swappable Small Form-Factor Pluggable Plus (SFP+) optical modules for 10GE optical fiber connections. The length of optical fiber can be selected according to the transmission distance.
Energy-Saving Design
Note: The S1700-52GR-4X has a fan, and the S1730S-L24P-A and S1730S-L24P-MA each have two fans. All these switches use air-cooled heat dissipation.
Cutting-Edge Surge Protection Capability
The S1700 unmanaged switch adopts the Huawei patented surge protection technology to protect the equipment. The surge protection capability reduces the probability of damages caused by lightning, even when the equipment cannot be grounded.
Figure 1. Front view of S1730S-L24T-A.
