Product Details:
|
| Name: | S5720 52P PWR LI AC | Model: | S5720 52P PWR LI AC Huawei S5700 Series Switches |
|---|---|---|---|
| Connector Type: | LC/PC | Warrranty: | 1 Year |
| Shipping: | DHL&FeDex | Software And Hardware Attributes: | Hardware |
| Product Line: | Enterprise Networking | Product Family: | Campus Switch & WLAN |
| Sub Product Family: | Fixed Switch | ||
| Highlight: | 370W POE AC power support,Huawei S5700 Series Switches,Huawei S5720 52P PWR LI AC |
||
Huawei S5720-52P-PWR-LI-AC is the Huawei S5720-LI series switch, providing 48 Ethernet 10/100/1000 ports, 4 Gig SFP, PoE+, and 370W POE AC power support. It’s an overseas model. Building on high-performance hardware and the Huawei Versatile Routing Platform (VRP), the S5720-LI series switches support intelligent stack (iStack), flexible Ethernet networking, and diversified security control. They support multiple Layer 3 routing protocols and provide high performance and service processing capabilities. The S5720-LI series switches are ideal for various scenarios such as enterprise campus network access and gigabit to the desktop.
Table 1 shows the quick spec.
| Model | S5720-52P-PWR-LI-AC |
| Ports | 48 Ethernet 10/100/1,000 Base-T ports, 4 Gig SFP ports |
| Power | AC power supply, supporting RPS (redundant power supply) |
| PoE Support | PoE+ |
| Forwarding performance | 87 Mpps / 144 Mpps |
| Switching capacity | 336 Gbit/s |
| Dimensions (W x D x H) | 442 mm x 310 mm x 43.6 mm |
Figure 1 shows the front panel.
Note:
| ① | Forty-eight PoE+ 10/100/1000BASE-T ports |
| ② | Four 1000BASE-X ports |
| ③ | One USB port |
| ④ | One console port |
| ⑤ | One PNP button |
