Dell PowerEdge R730 Xeon E5-2640 v4 32GB Dual 2TB SAS H330 Rack Server Specification |
|
| Product Series | Dell PowerEdge R730 Server |
| Model | Dell PowerEdge R730 Xeon E5-2640 v4 32GB Dual 2TB SAS H330 Rack Server |
| Customizable | Intel® Xeon® E5-2640 v4, Windows Server® 2012 Standard, 32GB Memory, Dual 2TB SAS H330 Hard Drive and a 3 Year ProSupport Warranty |
| Processor | Intel® Xeon® E5-2640 v4 2.4GHz,25M Cache,8.0GT/s QPI,Turbo,HT,10C/20T (90W) Max Mem 2133MHz |
| Operating System | Windows Server® 2012R2,Standard Ed,Factory Inst,No MED,2SKT,2VM,NO CAL |
| Memory | 32GB RDIMM, 2400MT/s, Dual Rank, x4 Data Width |
| Hard Drive | 2TB Hard Drive |
| Warranty | 3 Year ProSupport and NBD On-site Service |
| Chipset | Intel C610 series chipset |
| Embedded Hypervisor (Optional) |
Optional supported hypervisors: Microsoft® Windows Server® 2012, with Hyper-V® Citrix® XenServer® VMware® vSphere® ESXiTM |
| Storage | HDD: SAS, SATA, nearline SAS; SSD: SAS, SATA 16 x 2.5” – up to 29TB via 1.8TB hot-plug SAS hard drives 8 x 3.5” – up to 64TB via 8TB hot-plug nearline SAS hard drives |
| Drive Bays | Internal hard drive bay and hot-plug backplane: Up to 16 x 2.5” HDD: SAS, SATA, Near-line SAS SSD: SAS, SATA Up to 8 x 3.5” HDD: SAS, SATA, Near-line SAS SSD: SAS, SATA |
| Slots | Slot configuration #1: Slot 1: Half Length, Half Height, PCIe Gen3 x8 (x16 connector) low profile brackett Slot 2: Half Length, Half Height, PCIe Gen3 x8 (x16 connector) low profile brackett Slot 3: Half Length, Half Height, PCIe Gen3 x8 (x16 connector) low profile brackett Slot 4: Full Length, Full Height, PCIe Gen3 x16 (x16 connector) Slot 5: Full Length, Full Height, PCIe Gen3 x8 (x16 connector) Slot 6: Full Length, Full Height, PCIe Gen3 x8 (x16 connector) Slot 7: Full Length, Full Height, PCIe Gen3 x8 (x16 connector) Dedicated RAID card slot Slot configuration #2: Slot 1: Half Length, Half Height, PCIe Gen3 x8 (x16 connector) low profile bracket Slot 2: Half Length, Half Height, PCIe Gen3 x8 (x16 connector) low profile bracket Slot 3: Half Length, Half Height, PCIe Gen3 x8 (x16 connector) low profile bracket Slot 4: Full Length, Full Height, PCIe Gen3 x16 (x16 connector) Slot 5: Full Length, Full Height, PCIe Gen3 x8 (x16 connector) Slot 6: Full Length, Full Height, PCIe Gen3 x16 (x16 connector) Dedicated RAID card slot |
| RAID Controllers | Internal: PERC S130 PERC H330 PERC H730 PERC H730P External: PERC H830 |
| Network Controller | 4 x 1Gb, 2 x 1Gb + 2 x 10Gb, 4 x 10Gb |
| Communications | Broadcom® 5719 quad-port 1Gb NIC Broadcom 5720 dual-port 1Gb NIC Broadcom 57810 dual-port 10Gb DA/SFP+ CNA Broadcom 57810 dual-port 10Gb Base-T network adapter Intel® Ethernet I350 dual-port 1Gb server adapter Intel Ethernet I350 quad-port 1Gb server adapter Intel Ethernet X540 dual-port 10GBASE-T server adapter Mellanox® ConnectX®-3 dual-port 10Gb Direct Attach/SFP+ server network adapter Mellanox ConnectX-3 dual-port 40Gb Direct Attach/QSFP server network adapter Emulex® LPE 12000, single-port 8Gb Fibre Channel HBA Emulex LPE 12002, dual-port 8Gb Fibre Channel HBA Emulex LPe16000B, single-port 16Gb Fibre Channel HBA Emulex LPe16002B, dual-port 16Gb Fibre Channel HBA Emulex OneConnect OCe14102-U1-D 2-port PCIe 10GbE CNA QLogic® 2560, single-port 8Gb Optical Fibre Channel HBA QLogic 2562, dual-port 8Gb Optical Fibre Channel HBA Qlogic 2660, single-port 16GB, Fibre Channel HBA, full height Qlogic 2662, dual-port 16GB, Fibre Channel HBA, full height |
| Power | 1100W AC, 86 mm (Platinum) 1100W DC, 86 mm (Gold) 750W AC, 86 mm (Platinum) 750W AC, 86 mm (Diamond) 495W AC, 86 mm (Platinum) |
| Availability | ECC memory Hot-plug hard drives Hot-plug redundant cooling Hot-plug redundant power iDRAC8 Internal Dual SD Module Single Device Data Correction (SDDC) Spare Rank Tool-less chassis Support for high availability clustering and virtualization Proactive systems management alerts iDRAC8 with Lifecycle Controller |
| Chassis | Dimensions: H: 8.73 cm (3.44 in.) x W: 44.40 cm (17.49 in.) x D: 68.40 cm (26.92 in.) |
| Management | Dell OpenManage portfolio of systems management solutions, including: OpenManage Essentials console iDRAC8 with Lifecycle Controller iDRAC Direct iDRAC Quick Sync OpenManage Mobile |
