| Detailed Specification | |
| CPU |
2 4th Generation Intel®Xeon® Sapphire Rapids SP series 60 Cores for each Processor and 350W power consumption |
| Chipset | Intel®C741 |
| Memory | 32 DDR5 RDIMM Slots, 4800 MT/s Data Rate, 4 TB on 2 CPU Configuration |
| Raid Controller |
Dedicated PCIe HBA Controller or Raid Controller Standard PCIe HBA Controller or Raid Controller |
| FBWC | 8 GB Cache, support Supercapacitor protection |
| Storage |
29 Drives SAS/SATA HDD/SSD Drives,24 U.2 NVMe Drives SATA/NVMe M.2 Kit, DSD Model (2 x SD card kit) Front 12LFF bays, Rear 4LFF bays Front 25SFF bays, Rear 4SFF bays |
| Network |
1 Onboard 1Gbps Management Network Port 2 Onboard OCP 3.0 Slots for 4 GE or 2 10GE or 2 25GE or 2 100GE NICs PCIe Standard Slots for 1/10/25/100/200GE Ethernet Adapter |
| Expansion Slots |
10 PCIe Standard Slots (6 PCIe5.0 and 4 PCIe4.0) and 2 Onboard OCP 3.0 Slots; CXL1.1 |
| Ports |
Standard:1 VGA Rear Port, 3 USB 3.0 Ports (1 Front, 2 Rear), 1 USB 2.0 Internal Port, 1 Management Port Optional: 1 Rear Management Port, Mounting Bracket Kit with Type-C port, 1 VGA port, 1 Management Port |
| GPU | 8 Single-Slot or 4 Dual-Slot GPU Modules |
| Optical Drive | External Optical Disk Drive, Optional |
| Management |
HDM Management System (with dedicated management port) H3C iFIST/FIST, LCD touchable model,64M Video Cache |
| Security |
Intelligent Front Security Bezel Chassis Intrusion Detection TPM2.0 Silicon Root of Trust 2FA for HDM Intel SGX2.0 |
| Power supply |
Platinum 800W/1300W/1600W/2000W/2400W/2700W (1+1 redundancy) DC power supply (1+1 Redundancy) and Titanium Power Supply Hot swappable Redundant Fans |
| Standards | CE,UL , FCC,VCCI,CB, etc. |
| Operating temperature | 5°C to 45°C (41°F to 113°F) |
| Dimensions (H × W × D) |
2U Height Without a security bezel: 87.5 x 445.4 x 780 mm (3.44 x 17.54 x 30.7 in) With a security bezel: 87.5 x 445.4 x 808 mm (3.44 x 17.54 x 31.8 in) |
