Product Details:
|
| Model: | GLC-EX-SMD | Form Factor: | SFP |
|---|---|---|---|
| Wavelength: | 1310 Nm | Max Distance: | 40 Km |
| Data Rate: | 1.25Gb/s | Weight: | 0.025 Kg |
| Condition: | Brand New Sealed | Warranty: | 1 Year |
| Lead Time: | 2-3 Days | Payment: | T/T, Western Union, Paypal |
| Shipping: | DHL, Fedex, UPS | ||
| High Light: | Industrial DOM Transceiver Module,GLC-EX-SMD,1310nm SMF Transceiver Module |
||
The industry-standard Cisco® Small Form-Factor Pluggable (SFP) Gigabit Interface Converter links your switches and routers to the network. The hot-swappable input/output device plugs into a Gigabit Ethernet port or slot. Optical and copper models can be used on a wide variety of Cisco products and intermixed in combinations of 1000BASE-T, 1000BASE-SX, 1000BASE-LX/LH, 1000BASE-EX, 1000BASE-ZX, or 1000BASE-BX10-D/U on a port-by-port basis. GLC-EX-SMD is 1000BASE-EX long-wavelength; with DOM.
Table 2 shows the comparison between GLC-EX-SMD and GLC-BX-D.
| Product Code | GLC-EX-SMD | GLC-BX-D |
| Product Description | 1000BASE-EX long-wavelength; with DOM | 1000BASE-BX10-D downstream bidirectional single fiber; with DOM |
| Temperature Range | EXT | COM |
| DOM Support | Yes | Yes |
| Compatible OEM Part Number | GLC-EX-SMD | Optcore Part Number | OSP1250-3140DCR-CSC |
| Form Factor | SFP | Data Rate | 1.25Gb/s |
| Wavelength | 1310 nm | Fiber Type | SMF |
| Max Distance | 40 km | Optical Components | DFB/PIN |
| Transmitter Power | -5 ~ 0 dBm | Extinction ratio | > 9 dB |
| Receiver Sensitivity | < -24 dBm | Receiver Overload | > 0 dBm |
| Connector | LC Duplex | Digital Diagnostic Monitoring | Yes |
| Environment | Operating: 0°C to 70°C Storage: -40°C to 85°C |
Weight | 0.025 kg |
| Application | 1x Fiber Channel, Switch to Switch Interface
Gigabit Ethernet, Switched Backplane Applications Router/Server Interface, Other Optical Links |
Compliance | IEC/EN 61000-4-2,IEC-60825 FDA 21CFR 1040.10 and 1040.11 RoHS |
