Product Details:
|
| Model: | CE6881-48T6CQ-B | Transmission Rate: | 10/100/1000Mbps |
|---|---|---|---|
| Communication Mode: | Full-Duplex & Half-Duplex | Function: | LACP, SNMP, Stackable |
| Condition: | Brand New | Warranty: | 1 Year |
| Payment: | TT, Western Union, Paypal | Transportation: | DHL, Fedex, UPS |
| Shipping Time: | 5-7 Days | ||
| High Light: | CE6881-48T6CQ-B Huawei Switch,4 Fan Modules Huawei Network Switches |
||
The CloudEngine 6800 switches feature advanced hardware design with 10GE/25GE access interfaces, 40GE/100GE uplink interfaces, advanced data center features, high-performance stacking technologies, and flexible airflow capabilities. They are ideal for the core or aggregation level.
Together with the CloudEngine 16800 and 12800 series switches, the CloudEngine 6800 enables you to build scalable, simplified, open and secure networks.
| Item | Description | |
| Physical specifications |
Weight (with two power modules and two fan modules, calculated based on the heaviest model if multiple models are supported): 8.5 kg |
|
| Environment parameters | Temperature | Operating temperature:Operating temperature: 0°C to 40°C (32°F to 104°F) at altitude of 0-1800 m (0-5906 ft.)
NOTE: When the altitude is 1800-5000 m (5096-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). Storage temperature: -40°C to +70°C (-40°F to +158°F) |
| Relative humidity | 5% RH to 95% RH, noncondensing | |
| Altitude | < 5000 m (16404 ft.) | |
| Noise (sound pressure, 27°C) | Back-to-front airflow: < 57 dBA
Front-to-back airflow: < 58 dBA |
|
| Power specifications | Power source type | AC/DC/HVDC |
| AC power input | Rated input voltage range: 100 V AC to 240 V AC, 50/60 Hz
Maximum input voltage range: 90 V AC to 290 V AC, 47 Hz to 63 Hz |
|
| DC power input | Rated voltage range: -48 V DC to -60 V DC
Maximum voltage range: -38.4 V DC to -72 V DC |
|
| High-voltage DC power input | Rated voltage range: 240 V DC
Maximum voltage range: 190 V DC to 290 V DC |
|
| Rated input current | 600 W AC&240 V DC power module (PAC600S12 series):
8 A (100 V AC to 240 V AC) 4 A (240V DC) 1000 W DC power module (PDC1000S12 series): 30 A (-48 V DC to -60 V DC) |
|
| Chassis power consumption | Maximum power consumption | 349 W |
| Typical power consumption | 347 W (100% traffic load, 3 m network cables and copper cables, normal temperature, dual power modules)
362 W (100% traffic load, 3 m network cables and shortdistance optical modules, normal temperature, dual power modules) |
|
| Chassis heat dissipation | Maximum heat dissipation | 1542 BTU/hr |
| Surge protection | Power module:
AC: 6 kV in common mode and 6 kV in differential mode DC: 4 kV in common mode and 2 kV in differential mode HVDC: 4 kV in common mode and 2 kV in differential mode |
|
| Heat dissipation | Heat dissipation mode | Air cooling |
| Airflow | Front-to-back or back-to-front, depending on the fan modules and power modules | |
| Reliability and availability | Power module backup | 1+1 backup |
| Fan module backup | 3+1 backup | |
| Hot swap | Supported by all power modules and fan modules | |
| Mean time between failures (MTBF) | 48.16 years | |
| Mean time to repair (MTTR) | 1.78 hours | |
| Availability | 0.9999953209 | |
| Technical specifications | Processor | 1.4 GHz, four-core |
| DRAM Memory | 4 GB | |
| NOR Flash | 64 MB | |
| NAND Flash | 4 GB | |
| Stack | Service port supporting the stack function | 10GE optical ports and 100GE optical ports |
| Certification | Safety standards compliance
EMC standards compliance Environmental standards compliance |
|
