Huawei CE6820-48S6CQ-B Switch 48*10G SFP+ 6*100G QSFP28 2*AC Power Modules 4 Fan

Huawei CE6820-48S6CQ-B Switch 48*10G SFP+ 6*100G QSFP28 2*AC Power Modules 4 Fan
Huawei CE6820-48S6CQ-B Switch 48*10G SFP+ 6*100G QSFP28 2*AC Power Modules 4 Fan Huawei CE6820-48S6CQ-B Switch 48*10G SFP+ 6*100G QSFP28 2*AC Power Modules 4 Fan Huawei CE6820-48S6CQ-B Switch 48*10G SFP+ 6*100G QSFP28 2*AC Power Modules 4 Fan

Large Image :  Huawei CE6820-48S6CQ-B Switch 48*10G SFP+ 6*100G QSFP28 2*AC Power Modules 4 Fan

Product Details:
Place of Origin: China
Brand Name: Huawei
Certification: CE
Model Number: CE6820-48S6CQ-B
Payment & Shipping Terms:
Minimum Order Quantity: 1 PC
Price: Negotiable
Packaging Details: SEALED IN BAG
Delivery Time: 1-2 Days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 100 PCS / Month

Huawei CE6820-48S6CQ-B Switch 48*10G SFP+ 6*100G QSFP28 2*AC Power Modules 4 Fan

Description
Processor: 1.4 GHz, Four-core DRAM Memory: 4 GB
NOR Flash: 64 MB NAND Flash: 4 GB
Mean Time Between Failures (MTBF): 45.48 Years Mean Time To Repair (MTTR): 1.52 Hours
High Light:

48*10G Huawei Network Switches

,

AC Power Modules Huawei Network Switches

Huawei CloudEngine 6850 (CE6850 for short) series switches are next-generation 10G Ethernet switches designed for data centers and high-end campus networks, providing high-performance, high-density 10GE ports, and low latency. The CE6850 series uses an advanced hardware architecture with 40GE uplink ports and high density 10GE access ports. Using the Huawei VRP8 software platform, CE6850 series provide extensive data center service features and high stacking capability. In addition, the airflow direction (front-to-back or back-to-front) can be changed. CE6850 series can work with CE12800 switches to build an elastic, virtualized, high-quality fabric that meets the requirements of cloud-computing data centers.



Product Code CE6820-48S6CQ-B
Processor 1.4 GHz, four-core
DRAM Memory 4 GB
NOR Flash 64 MB
NAND Flash 4 GB
Mean time between failures (MTBF) 45.48 years
Mean time to repair (MTTR) 1.52 hours



CE6820-48S6CQ-B Specification

Item Description
Processor 1.4 GHz, four-core
DRAM Memory 4 GB
NOR Flash 64 MB
NAND Flash 4 GB
Mean time between failures (MTBF) 45.48 years
Mean time to repair (MTTR) 1.52 hours
Fixed ports Forty-eight 10GE SFP+ Ethernet optical ports Six 40GE/100GE QSFP28 Ethernet optical ports
Physical specifications Dimensions (H x W x D): 43.6 mm x 442.0 mm x 420.0 mm
Temperature

Operating temperature: 0°C to 40°C (32°F to 104°F) at altitude of 0-1800 m (0-5906 ft.)

Storage temperature: -40°C to +70°C (-40°F to +158°F)

Relative humidity 5% RH to 95% RH, noncondensing
Altitude < 5000 m (16404 ft.)
Noise (sound pressure, 27°C) Back-to-front airflow: < 55 dBA; Front-to-back airflow: < 55 dBA
Power source type AC/DC/HVDC
AC power input

Rated input voltage range: 100 V AC to 240 V AC, 50/60 Hz

Maximum input voltage range: 90 V AC to 290 V AC, 47 Hz to 63 Hz

DC power input

Rated voltage range: -48 V DC to -60 V DC

Maximum voltage range: -38.4 V DC to -72 V D

High-voltage DC power input

Rated voltage range: -48 V DC to -60 V DC

Maximum voltage range: 190 V DC to -290 V D

Rated input current

600 W AC&240 V DC power (PAC600S12 series): 8 A (100 V AC to 240 V AC); 4 A (240V DC)

1000 W DC power (PDC1000S12 series): 30 A (-48 V DC to -60 V DC)

Maximum power consumption 282 W
Typical power consumption

162 W (100% throughput, SFP+ high-speed cables on 48 ports and QSFP28 high-speed

cables on 6 ports, double power modules)

196 W (100% throughput, all optical interfaces on the switch are equipped with

the short-distance optical modules, double power modules)

Maximum heat dissipation 962 BTU/Hr
Heat dissipation mode Air cooling
Airflow Front-to-back or back-to-front, depending on the fan modules and power modules
Power module backup 1+1 backup
Fan module backup 3+1 backup
Hot swap Supported by all power modules and fan modules
Availability 0.99999618
Service port supporting the stack function 10GE optical ports, and 100GE optical ports



Huawei CE6820-48S6CQ-B Switch 48*10G SFP+ 6*100G QSFP28 2*AC Power Modules 4 Fan 0



Huawei CE6820-48S6CQ-B Switch 48*10G SFP+ 6*100G QSFP28 2*AC Power Modules 4 Fan 1

Huawei CE6820-48S6CQ-B Switch 48*10G SFP+ 6*100G QSFP28 2*AC Power Modules 4 Fan 2

Huawei CE6820-48S6CQ-B Switch 48*10G SFP+ 6*100G QSFP28 2*AC Power Modules 4 Fan 3

Huawei CE6820-48S6CQ-B Switch 48*10G SFP+ 6*100G QSFP28 2*AC Power Modules 4 Fan 4

Huawei CE6820-48S6CQ-B Switch 48*10G SFP+ 6*100G QSFP28 2*AC Power Modules 4 Fan 5
