Product Details:
|
Model: | SR630 | Base: | ThinkSystem 1U 2.5" Chassis With 8 Or 10 Bays |
---|---|---|---|
Cpu: | LIntel Xeon Gold 6348 28C 235W 2.6GHz Processor | Storage: | Select Storage Devices - No Configured RAID Required |
RAID: | ThinkSystem RAID 940-16i 8GB Flash PCIe Gen4 12Gb Adapter | HDD: | ThinkSystem 2.5" 2TB 7.2K SAS 12Gb Hot Swap 512n HDD |
SSD: | ThinkSystem M.2 5300 480GB SATA 6Gbps Non-Hot Swap SSD | Warranty: | 3 Year |
High Light: | ThinkSystem SR630 Network Rack Server,Rackable System 1u Server,2.6GHz Rack Server |
Server : ThinkSystem SR630 V2-3yr Warranty
Part number | Product Description | Qty |
7Z71CTO1WW | Server : ThinkSystem SR630 V2-3yr Warranty | 1 |
BH9Q | ThinkSystem 1U 2.5" Chassis with 8 or 10 Bays | 1 |
BFYE | Operating mode selection for: "Efficiency - Favoring Performance Mode" | 1 |
BB2L | Intel Xeon Gold 6348 28C 235W 2.6GHz Processor | 2 |
B966 | ThinkSystem 64GB TruDDR4 3200 MHz (2Rx4 1.2V) RDIMM | 4 |
5977 | Select Storage devices - no configured RAID required | 1 |
B8NZ | ThinkSystem RAID 940-16i 8GB Flash PCIe Gen4 12Gb Adapter | 1 |
AUM7 | ThinkSystem 2.5" 2TB 7.2K SAS 12Gb Hot Swap 512n HDD | 4 |
BB3T | ThinkSystem 1U 10x2.5" AnyBay Backplane | 1 |
B5XH | ThinkSystem M.2 SATA 2-Bay RAID Enablement Kit | 1 |
B919 | ThinkSystem M.2 5300 480GB SATA 6Gbps Non-Hot Swap SSD | 2 |
B8N2 | ThinkSystem 1U PCIe Gen4 x16/x16 Riser 1 | 1 |
B8NC | ThinkSystem 1U LP+LP BF Riser Cage Riser 1 | 1 |
B8MV | ThinkSystem 1U PCIe Gen4 x16 Riser 2 | 1 |
B5SS | ThinkSystem Broadcom 57416 10GBASE-T 2-port + 5720 1GbE 2-port OCP Ethernet Adapter | 1 |
ATZV | Emulex 16Gb Gen6 FC Dual-port HBA | 1 |
BQ0W | ThinkSystem V2 1100W (230Vac/115Vac) Platinum Hot Swap Power Supply | 2 |
6400 | 2.8m, 13A/100-250V, C13 to C14 Jumper Cord | 2 |
AUPW | ThinkSystem XClarity Controller Standard to Enterprise Upgrade | 1 |
BH9M | ThinkSystem V2/V3 1U Performance Fan Option Kit | 8 |
B8LA | ThinkSystem Toolless Slide Rail Kit v2 | 1 |
AVWN | Disable TPM on MB | 1 |
B7XZ | Disable IPMI-over-LAN | 1 |
B97M | ThinkSystem SR630 V2 MB | 1 |
AUNP | ThinkSystem RAID 930/940 SuperCap | 1 |
B9VR | ThinkSystem RAID 940-16i 8GB Flash PCIe Gen4 12Gb Adapter for SAS/SATA | 1 |
BHS7 | UEFI Operating Modes Support | 1 |
BK15 | High voltage (200V+) | 1 |
B8KK | ThinkSystem 1U 10x2.5" AnyBay HDD Type Label | 1 |
B8KY | Thinksystem WW Lenovo LPK | 1 |
AUTQ | ThinkSystem small Lenovo Label for 24x2.5"/12x3.5"/10x2.5" | 1 |
B7KN | ThinkSystem OCP NIC Label 1-4 with Speed | 1 |
B97H | ThinkSystem SR630 V2 Service Label for LC | 1 |
B97K | ThinkSystem SR630 V2 Model Number Label | 1 |
B97J | ThinkSystem SR630 V2 Agency Label | 1 |
B22B | DC Warning Label for PRC | 1 |
B97B | XCC Label | 1 |
BBBH | ThinkSystem 1100W Pt HV Power Rating LBL PRC | 1 |
B8GY | M.2 Module Cable | 1 |
BC0M | ThinkSystem Supercap Cable | 1 |
BA25 | ThinkSystem SR630 V2 10x2.5" BP Power Cable | 1 |
BA1N | ThinkSystem SR630 V2 MB to 10x2.5" AnyBay BP Cable 755mm | 1 |
BA2P | ThinkSystem 1U SFF RAID to Front 10x2.5" AnyBay Backplane SAS/SATA G4 Y Cable | 1 |
BA2Q | ThinkSystem 1U SFF RAID to Front 10x2.5" AnyBay Backplane SAS/SATA G4 Cable | 1 |
BE0E | N+N Redundancy With Over-Subscription | 1 |
BAXJ | China CPK | 1 |
B955 | ThinkSystem 4R ICX CPU HS Clip | 2 |
B8N7 | ThinkSystem 1U MS LP Riser Cage Riser1&2 | 1 |
AVWK | ThinkSystem EIA Plate with Lenovo Logo | 1 |
B173 | Companion Part for XClarity Controller Standard to Enterprise Upgrade in Factory | 1 |
B989 | ThinkSystem V2 1U Package | 1 |
B984 | ThinkSystem 1U PLV Top Cover Sponge | 1 |
BH9R | 10x2.5" Media Bay w/ Cable | 1 |
BHJS | 1U MB PSU Airduct for CPU>125W | 1 |
BK70 | ThinkSystem V2/V3 1U Supercap Holder Kit | 1 |
B975 | ThinkSystem V2 Performance Heatsink | 2 |
AUWG | Lenovo ThinkSystem 1U VGA Filler | 1 |
AURS | Lenovo ThinkSystem Memory Dummy | 28 |
AVEN | ThinkSystem 1x1 2.5" HDD Filler | 6 |
A2HP | Configuration ID 01 | 1 |
5374CM1 | Configuration Instruction | 1 |
B8Q6 | ThinkSystem RAID 940-16i 8GB Flash PCIe Gen4 12Gb Adapter Placement | 1 |
A2JX | Controller 01 | 1 |
A2HP | Configuration ID 01 | 1 |
5641PX3 | XClarity Pro, Per Endpoint w/3 Yr SW S&S | 1 |
1340 | Lenovo XClarity Pro, Per Managed Endpoint w/3 Yr SW S&S | 1 |
3444 | Registration only | 1 |
