Product Details:
|
| Condition: | Original New | Warranty: | 1 Year |
|---|---|---|---|
| Lead Time: | 1-2 Days | Application: | Intdoor |
| Transmission Rate: | 1000/10000Mbps | Ports: | 24 |
| Brand: | Huawei | Switch Capacity: | 880 Gbit/s/2.72 Tbit/s |
| High Light: | AP Mainframe Wireless Access Point,AirEngine Wireless Access Point,Huawei Indoor Wifi 6 Access Point |
||
Table 1 shows the quick spec.
| Model | Huawei AirEngine 6760-X1 |
| Maximum Number of Users | ≤ 1024 (dual-radio mode) ≤ 1152 (triple-radio mode) Note: The actual number of users varies according to the environment |
| Port | 1 x 10 GE, 1 x GE electrical, and 1 x 10 GE SFP+ |
| IoT | Built-in IoT slots |
| Antenna Type | AirEngine 6760-X1: Built-in Smart Antennas |
| Radio Protocols | 802.11a/b/g/n/ac/ac Wave 2/ax |
| Maximum Rate | Basic capability: 8.35 Gbit/s RTU license upgrade: 10.75 Gbit/s |
Table 2 shows the comparison.
| Model | Huawei AirEngine 6760-X1 | AirEngine 5760-51 |
| Maximum Number of Users | ≤ 1024 (dual-radio mode) ≤ 1152 (triple-radio mode) Note: The actual number of users varies according to the environment |
≤ 1024 (dual-radio mode) ≤ 1152 (triple-radio mode) Note: The actual number of users varies according to the environment. |
| Port | 1 x 10 GE, 1 x GE electrical, and 1 x 10 GE SFP+ | 1 x 5 GE and 1 x GE electrical |
| IoT | Built-in IoT slots | Built-in IoT slots |
| Antenna Type | Built-in Smart Antennas | Built-in Smart Antennas |
| Radio Protocols | 802.11a/b/g/n/ac/ac Wave 2/ax | 802.11a/b/g/n/ac/ac Wave 2/ax |
| Maximum Rate | Basic capability: 8.35 Gbit/s RTU license upgrade: 10.75 Gbit/s |
Basic capability: up to 5.37 Gbit/s RTU license upgrade: up to 5.95 Gbit/s |
Huawei AirEngine 6760-X1 Specification |
|
| Dimensions (H x W x D) | 61 mm x 220 mm x 220 mm |
| Power Input | DC: 48 V ± 10% PoE power supply: in compliance with IEEE 802.3bt |
| Maximum Number of Users | ≤ 1024 (dual-radio mode) ≤ 1152 (triple-radio mode) Note: The actual number of users varies according to the environment |
| Port | 1 x 10 GE, 1 x GE electrical, and 1 x 10 GE SFP+ |
| IoT | Built-in IoT slots |
| Operating Temperature | –10°C to 50°C |
| Antenna Type | AirEngine 6760-X1: Built-in Smart Antennas |
| MIMO: Spatial Streams | Basic capability: 2.4 GHz: 4x4:4; 5 GHz: 6x6:6 Capability upgrade via RTU license: 2.4 GHz: 4x4:4; 5 GHz: 8x8:8 2.4 GHz: 4x4:4; 5 GHz-0: 4x4:4; 5 GHz-1: 4x4:4 |
| Radio Protocols | 802.11a/b/g/n/ac/ac Wave 2/ax |
| Maximum Rate | Basic capability: 8.35 Gbit/s RTU license upgrade: 10.75 Gbit/s |
| C1000-48P-4G-L | C9500-NM-8X | CAB-SPWR-30CM |
| C1000-48T-4G-L | C9800-F-X-K9 | C9200L-STACK-KIT |
| WS-C2960X-24TS-LL | N9K-C93180YC-FX | PWR-C4-950WAC-R |
| WS-C2960X-24PSQ-L | N3K-C3172PQ-XL | C9200-NM-4G |
| WS-C2960X-24PS-L | N2K-C2348UPQ | C9200-NM-4X |
| WS-C2960X-48TS-L | AIR-AP1832I-H-K9 | C9300-NM-4G |
| WS-C2960L-24PS-AP | AIR-AP2802I-H-K9 | C9300-NM-8X |
| WS-C2960L-16TS-LL | C9115AXI-H | GLC-LH-SMD |
| WS-C2960L-8TS-LL | C9120AXI-H | SFP-10G-SR |
| WS-C3560-48FS-S | AIR-AP1562I-H-K9 | SFP-10G-LR |
| WS-C2960X-24PS-L | AIR-AP1562D-H-K9 | SFP-10G-SR-S |
| C9200L-48P-4X-E | C9800-L-C-K9 | SFP-10G-LR-S |
| C9200L-48P-4G-E | C9800-L-F-K9 | GLC-TE |
| C9200L-24T-4G-E | AP505 | SFP-H10GB-CU2M |
| C9300-24T-A | AP515 | MA-CBL-40G-3M |
| C9300-48T-A | CP-3905 | GLC-LH-SMD= |
| C9300-24S-A | CP-7821-K9 | ISR4331/K9 |
| C9300-48S-A | CP-8832-MIC-WIRED | ISR4331/K9 RF |
| C9300-48P-E | CS-MIC-TABLE-J | FPR2110-ASA-K9 |
| C9300-24P-E | AIR-AP3802I-E-K9 | FPR2110-ASA-K9 |
| C9300L-24T-4G-E | C1111-8P | FPR2120-ASA-K9 |
| C9300L-48T-4G-E | PWR-C5-125WAC | FPR2130-ASA-K9 |
| C9300-NM-8X | PWR-C5-1KWAC | C9200-NM-4G= |
| C9400-LC-24S | PWR-C6-125WAC | C9200-NM-4G= |
| C9400-LC-48S | STACK-T1-50CM | C9200L-24P-4G-CE |
| C9500-24Y4C-A | STACK-T1-1M | C9200L-24P-4G-CE |
| C9500-48Y4C-A | STACK-T1-3M | C9200L-48P-4G-E |
