Product Details:
|
| Model: | SFP-10G-iLR | Name: | Huawei SFP-10G-iLR Optical Transceiver |
|---|---|---|---|
| Key Words: | Copper Sfp | Detail: | Optical Transceiver,SFP+,9.8G,Single-mode Module(1310nm,1.4km,LC) |
| Transceiver Form Factor: | SFP+ | Transmission Speed: | 10 Gbit/s |
| Center Wavelength (nm): | 1310 | Standard Compliance: | 10GBASE-iLR |
| High Light: | 10 Gbit/s Optical Transceiver,SFP-10G-ILR Optical Transceiver,Huawei High Speed SFP Transceiver |
||
Huawei SFP-10G-iLR Optical Transceiver SFP - 10G - iLR huawei high speed transceiver
Optical Transceiver,SFP+,9.8G,Single-mode Module 1310nm,1.4km,LC.
| Product Code | SFP-10G-iLR |
| Part Number | 02311BJJ |
| Description | Optical Transceiver, SFP+,9.8G, Single-mode Module(1310nm,1.4km,LC) |
| UOM | PCS |
| Pack Weight(kg) | 0.04 |
| Pack Volume(m^3) | 0.000303 |
| Pack Dimension(D*W*H mm) | 130*73*32 |
| Net Dimension(D*W*H mm) | 145*80*35 |
| Transceiver form factor | SFP+ |
| Transmission speed | 10 Gbit/s |
| Center wavelength (nm) | 1310 |
| Standard compliance | 10GBASE-iLR |
| Connector type | LC |
| Applicable cable and maximum transmission distance | Single-mode fiber: 1.4 km |
| Transmit power (dBm) | -8.2 to +0.5 |
| Maximum receiver sensitivity (dBm) | -14.4 |
| Overload power (dBm) | 0.5 |
| Extinction ratio (dB) | 3.5 |
Our stock support good price
