AP2051DN-E Indoor Wireless WiFi Access Point AP2051DN-E

AP2051DN-E  Indoor Wireless WiFi Access Point AP2051DN-E
AP2051DN-E  Indoor Wireless WiFi Access Point AP2051DN-E AP2051DN-E  Indoor Wireless WiFi Access Point AP2051DN-E

Large Image :  AP2051DN-E Indoor Wireless WiFi Access Point AP2051DN-E

Product Details:
Place of Origin: CHINA
Brand Name: HUAWEI
Certification: CE
Model Number: AP2051DN-E

AP2051DN-E Indoor Wireless WiFi Access Point AP2051DN-E

Description
Model Number: AP2051DN-E Type: Enterprise Wireless Access Point
Dimensions (H X W X D): 32.5 Mm X 86 Mm X 150 Mm Interface Types: 1 X GE;4 X GE 2 X Pass-through RJ45 Port 1 X USB Port
Maximum Number Of Users: ≤ 256 MIMO: Spatial Streams: 2 X 2:2
Antenna Type: Built-in Smart Antennas Maximum Transmit Power: 2.4G: 23 DBm (combined Power) 5G: 23 DBm (combined Power) MIMO: Spatial Streams: 2 X 2:2
High Light:

Fiber Optic Transceiver Module Indoor

,

Wireless Sfp Transceiver Module

,

Fiber Transceiver Module AP2051DN-E

AP2051DN-E Indoor Wireless WiFi Access Point AP2051DN-E



802.11ac Wave 2 Access Points AP2051DN-E

Product Description

AP2051DN and AP2051DN-E are the latest-generation gigabit wall plate Access Points (APs) that comply with 802.11ac W ave 2. They have built-in smart antennas and support 2 x 2 MIMO and two spatial streams, achieving a rate of 1.267 Gbit/s. The AP2051DN and AP2051DN-E are applicable to environments with complex wall structures and high-density rooms, such as schools, hotels, hospitals, and office meeting rooms.





Product Description
Specifications AP2051DN and AP2051DN-E
Dimensions (H x W x D) 32.5 mm x 86 mm x 150 mm
Power Input DC: 45.6V to 57V
PoE power supply: In compliance with IEEE 802.3af/at
Maximum Power Consumption AP2051DN: 11.5W (excluding the output power of the USB port)
AP2051DN-E: 11.5W (excluding the output power of the USB port and PoE_OUT port)

Note: The actual maximum power consumption depends on local laws and regulations
Interface types Uplink: 1 x GE
Downlink: 4 x GE
2 x Pass-through RJ45 port
1 x USB port
Built-in Blue tooth BLE4.1 (supported by the AP2051DN-E)
PoE OUT Supported by AP2051DN-E: Maximum 13.6W (802.3at-compliant, 48V DC, supported only by GE4)
Operating Temperature 0°C to 40°C
Antenna Type Built-in smart antennas
Maximum Number of Users ≤ 256
Maximum Transmit Power 2.4G: 23 dBm (combined power)
5G: 23 dBm (combined power)

Note: The actual transmit power depends on local laws and regulations.
MIMO: Spatial Streams 2 x 2:2
Radio Protocols 802.11a/b/g/n/ac/ac wave 2
Maximum Rate 1.267 Gbit/s



AP2051DN-E  Indoor Wireless WiFi Access Point AP2051DN-E 0



AP2051DN-E  Indoor Wireless WiFi Access Point AP2051DN-E 1
