Product Details:
|
| Name: | H3C SecPath PSR150 - A1 & PSR150 - D1 Power Modules User Manual - 6W102 | Model: | PSR150-A1-D |
|---|---|---|---|
| Detail: | 150W Asset-manageable AC Power Module | Products Status: | Stock,Used |
| Function: | Stackable,QoS,VLAN Support,SNMP,LACP | Warranty: | One Year |
| Condition: | 100% Original Brand | Manufacturer: | Huawei |
| Dimensions (w X D X H): | 420x220x43.6mm | Subtype: | Gigabit Ethernet |
| High Light: | H3C Huawei Power Module,SecPath Switch Power Module,Ethernet Huawei Power Module |
||
H3C SecPath PSR150 - A1 & PSR150 - D1 Power Modules User Manual - 6W102
The PSR150-A1 is an AC-input and DC-output power module. The PSR150-D1 is a DC-input and DC-output power module. Both power modules provide an output voltage of 12 V and a maximum output of 150 W.
These power modules have the following features:
· Provide output overvoltage, short-circuit, overcurrent, and overtemperature protections. See for the protection and auto-recovery features of the power modules.
· Two power modules can be connected in parallel to achieve 1+1 redundancy and load sharing.
· Hot swappable. When you hot swap a power module, make sure the device can operate correctly with the remaining power modules.
| Item | Specifications |
| Rated voltage range |
· PSR150-A1 ¡ AC input: 100 VAC to 240 VAC @ 50 Hz or 60 Hz ¡ DC input: 240 VDC · PSR150-D1: –48 VDC to –60 VDC |
| Max voltage range |
· PSR150-A1 ¡ AC input: 90 VAC to 264 VAC @ 47 Hz or 63 Hz ¡ DC input: 192 to 290 VDC · PSR150-D1: –36 VDC to –72 VDC |
| Output voltage | 12 V |
| Max output current | 12.5 A |
| Max output power | 150 W |
| Dimensions (H × W × D) | 41.1 × 101.6 × 177 mm (1.62 × 4 × 6.97 in) |
| Operating temperature | –5°C to +55°C (25°F to 131°F) |
| Storage temperature | –40°C to +70°C (–40°F to +158°F) |
