Duplex Huawei 6800 Series CloudEngine Switches Hardware

Duplex Huawei 6800 Series CloudEngine Switches Hardware
Duplex Huawei 6800 Series CloudEngine Switches Hardware Duplex Huawei 6800 Series CloudEngine Switches Hardware Duplex Huawei 6800 Series CloudEngine Switches Hardware Duplex Huawei 6800 Series CloudEngine Switches Hardware

Large Image :  Duplex Huawei 6800 Series CloudEngine Switches Hardware

Product Details:
Place of Origin: China
Brand Name: Huawei
Certification: CE
Model Number: 8850-EI-B-BOB

Duplex Huawei 6800 Series CloudEngine Switches Hardware

Description
Name: CloudEngine 8800, 7800, 6800, And 5800 Series Switches Hardware Description (Versions Earlier Than V200R020C00) Model: 8850-EI-B-BOB
Connector Type: Depending On The Optical Module Standards Compliance: IEEE802.3ba
Working Mode: Full-duplex
High Light:

Duplex Huawei Enterprise Switches

,

Huawei Cloudengine 6800 Switches

,

Huawei Cloud Switch Hardware

CloudEngine 8800, 7800, 6800, and 5800 Series Switches Hardware Description (Versions earlier than V200R020C00)

Technical specifications

Item

Description

Physical specifications
  • Dimensions (W x D x H): 442.0 mm x 420.0 mm x 43.6 mm (17.4 in. x 16.5 in. x 1.72 in.)
  • Weight (with two power modules and two fan modules, calculated based on the heaviest model if multiple models are supported): 8.8 kg (19.40 lb)
Environment parameters Temperature
  • Operating temperature: 0°C to 40°C (32°F to 104°F) at altitude of 0-1800 m (0-5906 ft.)
    NOTE:

    When the altitude is 1800-5000 m (5096-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).

  • Storage temperature: -40°C to +70°C (-40°F to +158°F)
Relative humidity 5% RH to 95% RH, noncondensing
Altitude < 5000 m (16404 ft.)
Noise (sound pressure, 27°C)
  • Back-to-front airflow: < 65 dBA
  • Front-to-back airflow: < 65 dBA
Power specifications Power source type AC/DC
AC power input
  • Rated input voltage range: 100 V AC to 240 V AC, 50/60 Hz
  • Maximum input voltage range: 90 V AC to 290 V AC, 47 Hz to 63 Hz
DC power input
  • Rated voltage range: -48 V DC to -60 V DC
  • Maximum voltage range: -38.4 V DC to -72 V DC
High-voltage DC power input Not supported
Rated input current
  • 350 W DC power (PDC-350WA series): 11 A (-48 V DC to -60 V DC)
  • 600 W AC power (PAC-600WA series): 9 A (100 V AC to 240 V AC)
  • 600 W DC power (PDC600S12 series): 20 A (-48 V DC to -60 V DC)
Chassis power consumption Maximum power consumption 420W
Typical power consumption 259 W (100% throughput, SFP28 cables on 48 ports and QSFP28 cables on 8 ports, double power modules)
Chassis heat dissipation Maximum heat dissipation 1433 BTU/hr
Typical heat dissipation 884 BTU/hr (100% throughput, SFP28 cables on 48 ports and QSFP28 cables on 8 ports, double power modules)
Surge protection
Power module:
  • AC: 6 kV in common mode and 6 kV in differential mode
  • DC: 2 kV in common mode and 1 kV in differential mode
Heat dissipation Heat dissipation mode Air cooling
Airflow Front-to-back or back-to-front, depending on the fan modules and power modules
Reliability and availability Power module backup 1+1 backup
Fan module backup

1+1 backup not supported

NOTE:

A CE6800 chassis uses two fan modules, with each fan module containing two fans. The four fans in the chassis work in 3+1 backup mode.

Hot swap Supported by all power modules and fan modules
Mean time between failures (MTBF) 38.85
Mean time to repair (MTTR) 1.48
Availability 0.999997178
Technical specifications Processor 1.5 GHz, 8-core
DRAM Memory 4 GB
NOR Flash 32 MB
NAND Flash 2 GB
Stack Service port supporting the stack function 25GE optical ports and 100GE optical ports
Certification
  • Safety standards compliance
  • EMC standards compliance
  • Environmental standards compliance
