S7700 Optical Transceiver Module Switch GE SFP Interface Card 48 Port

S7700 Optical Transceiver Module Switch GE SFP Interface Card 48 Port
S7700 Optical Transceiver Module Switch GE SFP Interface Card 48 Port S7700 Optical Transceiver Module Switch GE SFP Interface Card 48 Port S7700 Optical Transceiver Module Switch GE SFP Interface Card 48 Port S7700 Optical Transceiver Module Switch GE SFP Interface Card 48 Port

Large Image :  S7700 Optical Transceiver Module Switch GE SFP Interface Card 48 Port

Product Details:
Place of Origin: CHINA
Brand Name: HUAWEI
Certification: CE
Model Number: LSS7G48SX6S0

S7700 Optical Transceiver Module Switch GE SFP Interface Card 48 Port

Description
Products Status: Stock Brand Name:: Original
Place Of Origin: China Condition: 100% Original Brand
Brand Name: Original Warranty: One Year
Certification: FCC Dimensions (H X W X D): 35.1 Mm X 397.2 Mm X 430.4 Mm
Maximum Power Consumption: 147 W
High Light:

48 Port SFP Network Card

,

Switch SFP Pcie Card

,

Transceiver SFP Interface Card

48-Port 03033ATD S7700 Series Switch GE SFP Interface Card (X6S, SFP) LSS7G48SX6S0

Version Mapping

Table 1 Switch chassis and software versions matching the card

Card Name

S7700 Chassis

LSS7G48SX6S0

S7703 chassis: supported in V200R013C02 and later versions

S7703 PoE, S7706, S7706 PoE, and S7712 chassis: supported in V200R019C00 and later versions

Introduction

The LSS7G48SX6S0 provides high performance, large entry sizes, and a large buffer for data switching. This card is highly integrated and has a large port density.

The LSS7G48SX6S0 can be installed in:

  • Slots 01 to 03 in an S7703 or S7703 PoE chassis.
  • Slots 01 to 06 in an S7706 or S7706 PoE chassis.
  • Slots 01 to 12 in an S7712 chassis.

Functions

The LSS7G48SX6S0 provides the following functions:
  • Communicates with the MPU and works under the control of the MPU.
  • Searches for routes and destination addresses of data packets for forwarding.
  • Forwards data packets.
Table 2 Functions of the LSS7G48SX6S0

Function

Description

Basic functions Provides forty-eight GE optical ports for data access and switching.
Distributed forwarding Performs concurrent data forwarding using a distributed data plane.
Hot swapping The LSS7G48SX6S0 is hot swappable.



Specifications

Table 3 Specifications of the LSS7G48SX6S0

Item

Description

Physical specifications
  • Dimensions (H x W x D): 35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.)
  • Weight: 3.2 kg (7.05 lb)
  • Maximum power consumption: 147 W
  •
S7700 Optical Transceiver Module Switch GE SFP Interface Card 48 Port 0
S7700 Optical Transceiver Module Switch GE SFP Interface Card 48 Port 1
