Huawei Outdoor Wireless Access Point AP ​802.11ac Wave 2

Huawei Outdoor Wireless Access Point AP ​802.11ac Wave 2
Huawei Outdoor Wireless Access Point AP ​802.11ac Wave 2 Huawei Outdoor Wireless Access Point AP ​802.11ac Wave 2 Huawei Outdoor Wireless Access Point AP ​802.11ac Wave 2 Huawei Outdoor Wireless Access Point AP ​802.11ac Wave 2

Large Image :  Huawei Outdoor Wireless Access Point AP ​802.11ac Wave 2

Product Details:
Place of Origin: China
Brand Name: Huawei
Certification: CE
Model Number: AP6750-10T

Huawei Outdoor Wireless Access Point AP ​802.11ac Wave 2

Description
Quick Details Model Number: AP6750-10T Dimensions (H X W X D): 47 X 220 X 220 Mm
Name: Huawei AP6750 - 10T Is An 802.11ac Wave 2 Wi - Fi 5 Access Point AP Type: Enterprise Wireless Access Point
Power Input: DC: 12 V ± 10% Maximum Power Consumption: 19.3 W (excluding USB Input)
Antenna Type: Adaptive Array Antennas Radio Protocols: 802.11a/b/g/n/ac/ac Wave 2
Warranty: 1 Year
High Light:

802.11ac Wave 2 Wifi Access Point

,

Huawei Access Point AP

,

12V Outdoor Access Point AP

Huawei AP6750 - 10T is an 802.11ac Wave 2 Wi - Fi 5 Access Point AP



HUAWEI Access Point (AP) AP6750-10T

Product Description



Huawei AP6750-10T is an 802.11ac Wave 2 Access Point (AP) with built-in adaptive array antennas to enhance the coverage range and improve signal quality. In addition, AP6750-10T offers triple radio channels: a single 2.4 GHz channel and two 5 GHz channels, achieving rates of up to 3 Gbit/s.

While the single 2.4 GHz channel supports 2x2 Multiple-Input Multiple-Output (MIMO) and two spatial streams, one 5 GHz channels supports 2x2 MIMO and two spatial streams; the other 5 GHz channel supports 4x4 MIMO and four spatial streams. AP6750-10T is designed for high-density scenarios such as e-classrooms and supermarkets.

Detailed Images

HUAWEI  Access Point (AP) AP6750-10T

Specification



Spsecificsations AP6750-10T
Dimensions (H x W x D) 47 x 220 x 220 mm
Power Input DC: 12 V ± 10%
PoE: In compliance with IEEE 802.3at
Maximum Power Consumption 19.3 W (excluding USB input)
Note: Actual maximum power consumption depends on local laws and regulations.
Maximum Number of Users ≤ 768
Note: Actual number of users varies based on the environment.
Maximum Transmit Power 2.4 GHz: 23 dBm (combined power)
5 GHz-0: 24 dBm (combined power)
5 GHz-1: 27 dBm (combined power)
Note: Actual transmit power depends on local laws and regulations.
Operating Temperature –10°C to 50°C
Antenna Type Adaptive array antennas
MIMO: Spatial Streams 2.4G: 2 x 2:2; 5G-1: 2 x 2:2; 5G-2: 4 x 4:4
Radio Protocols 802.11a/b/g/n/ac/ac Wave 2
Maximum Rate 3 Gbit/s



Huawei S5735-L24P4S-A Switches 24 x 10/100/1000Base-T ports, 4 x GE SFP ports, PoE+ 0Huawei S5735-L24P4S-A Switches 24 x 10/100/1000Base-T ports, 4 x GE SFP ports, PoE+ 1
