Product Details:
|
| Product Code: | SFP-10G-USR | Transceiver Form Factor: | SFP+ |
|---|---|---|---|
| Transmission Speed: | 10 Gbit/s | Center Wavelength (nm): | 850 |
| Standard Compliance: | 10Gbase-USR | Applicable Cable And Maximum Transmission Distance: | Multimode Fiber (OM3): 0.1 Km |
| Transmit Power (dBm): | -7.3 To -1.0 | Operating Temperature: | 0°C To 70°C (32°F To 158°F) |
HW SFP-10G-USR compatible SFP+ transceiver supports up to 100m link lengths over OM3 MMF via an LC duplex connector. This transceiver is compliant with SFF-8431, SFF-8432 and IEEE 802.3ae standards. Digital diagnostics monitoring is available via a 2-wire serial interface, as specified in SFF-8472. Featuring low power consumption and high speed, this 10G SFP+ transceiver is ideal for data centers, enterprise wiring closets, service provider transport applications, Radio & Baseband Units, etc.
| Product Code | SFP-10G-USR |
| Transceiver form factor | SFP+ |
| Transmission speed | 10 Gbit/s |
| Center wavelength (nm) | 850 |
| Standard compliance | 10Gbase-USR |
| Connector type | LC |
| Applicable cable and maximum transmission distance | Multimode fiber (OM3): 0.1 km |
| Transmit power (dBm) | -7.3 to -1.0 |
| Maximum receiver sensitivity (dBm) | -10.7 |
| Overload power (dBm) | 0.5 |
| Extinction ratio (dB) | 3.0 |
| Operating temperature | 0°C to 70°C (32°F to 158°F) |
| Net Dimension(D x W x H mm) |
145 x 80 x 35
|
SFP-10G-USR Specification |
|
| Transceiver form factor | SFP+ |
| Transmission speed | 10 Gbit/s |
| Center wavelength (nm) | 850 |
| Standard compliance | 10Gbase-USR |
| Connector type | LC |
| Applicable cable and maximum transmission distance | Multimode fiber (OM3): 0.1 km |
| Transmit power (dBm) | -7.3 to -1.0 |
| Maximum receiver sensitivity (dBm) | -10.7 |
| Overload power (dBm) | 0.5 |
| Extinction ratio (dB) | 3.0 |
| Operating temperature | 0°C to 70°C (32°F to 158°F) |
| Net Dimension(D x W x H mm) | 145 x 80 x 35 |
