Mitsubishi FX3U-4DA-ADP 4-Channel Analog Output Adapter for FX3U/FX3UC PLCs | High Precision Voltage/Current Output Module

Large Image : Mitsubishi FX3U-4DA-ADP 4-Channel Analog Output Adapter for FX3U/FX3UC PLCs | High Precision Voltage/Current Output Module

Product Details:

Place of Origin:	China
Brand Name:	Siemens
Certification:	CE
Model Number:	FX3U-4DA-ADP

Payment & Shipping Terms:

Minimum Order Quantity:	1
Delivery Time:	2-3 days
Payment Terms:	T/T

Contact Now

Mitsubishi FX3U-4DA-ADP 4-Channel Analog Output Adapter for FX3U/FX3UC PLCs | High Precision Voltage/Current Output Module

Description

Product Name:	PLC Industrial Control	Part Number:	FX3U-4DA-ADP
Shipment:	DHL	Condition:	New
Lead Time:	2-3 Days	Warranty:	1 Year
Keywords:	FX3U-4DA-ADP
Highlight:	Mitsubishi FX3U analog output adapter , 4-channel PLC output module , high precision voltage current module

Siemens FX3U-4DA-ADP Overview

The Mitsubishi FX3U-4DA-ADP is a compact 4-channel analog output adapter for FX3U/FX3UC/FX3S/FX3G PLCs, converting digital PLC signals to precise 0-10V DC voltage or 4-20mA DC current outputs. With 12-bit resolution, 200μs/channel fast conversion, and independent channel configuration, it features overvoltage/overcurrent/reverse polarity protection for stable performance in industrial automation. Easy to integrate, it optimizes analog control for actuators like VFDs and proportional valves, boosting FX3 Series PLC system flexibility and precision.

Figure 1 shows the front panel of FX3U-4DA-ADP.

Quick Specs.

Table 1 shows the Quick Specs.

Parameter	Value
Model	FX3U-4DA-ADP
Type	4-Channel Analog Output Adapter
Applicable PLC	FX3U/FX3UC Series
Output Channels	4 (CH1-CH4, independently configurable)
Output Type	Voltage (0-10V DC); Current (4-20mA DC)
Resolution	12-bit (Voltage: 2.5mV/step; Current: 4μA/step)
Conversion Speed	200μs/channel (FX3U/FX3UC); 250μs/channel (FX3S/FX3G)
Accuracy	±0.5% FS (25°C±5°C); ±1.0% FS (0-55°C)
I/O Points Occupied	8 points (4 inputs, 4 outputs)
Weight	Approx. 0.15kg
Operating Temperature	0-55°C
Storage Temperature	-20-65°C
Power Supply	DC 24V (21.6-26.4V)
Power Consumption	Max. 2W
Protection	Overvoltage, Overcurrent, Reverse Polarity
Certifications	UL, cUL, CE, RoHS

Detailed Specification

Category	Item	Details
General	Model	FX3U-4DA-ADP
	Type	4-Channel Analog Output Adapter for MELSEC-F Series PLCs
	Applicable PLC	FX3U, FX3UC, FX3S, FX3G Series PLCs
	I/O Points Occupied	8 points (4 inputs, 4 outputs)
	Weight	Approx. 0.15kg
	Dimensions (W×H×D)	Approx. 35×90×60mm
	Operating Temperature	0-55°C (No condensation or icing)
	Storage Temperature	-20-65°C
	Relative Humidity	35-85% RH (No condensation)
	Vibration Resistance	10-55Hz, 0.5mm double amplitude (10-55Hz), 50m/s² (5.1G) acceleration (55-150Hz)
	Shock Resistance	150m/s² (15.3G) for 11ms, 3 times each in X, Y, Z directions
	Power Supply	DC 24V (21.6-26.4V DC), 0.1A (Max.)
	Power Consumption	Max. 2W
Analog Output	Output Channels	4 channels (CH1-CH4), independently configurable
	Voltage Output	0-10V DC, Load: 5kΩ-1MΩ
	Current Output	4-20mA DC, Load: ≤500Ω
	Resolution	12-bit (Voltage: 2.5mV/step; Current: 4μA/step)
	Total Accuracy	±0.5% FS (25°C±5°C); ±1.0% FS (0-55°C)
	Conversion Speed	200μs/channel (FX3U/FX3UC); 250μs/channel (FX3S/FX3G)
	Output Protection	Overvoltage, Overcurrent, Reverse Polarity Protection
Digital I/O	Digital Inputs	4 (for channel setting, mode selection)
	Digital Outputs	4 (for status indication, alarm output)
Certifications	Certifications	UL, cUL, CE (EMC, RoHS), KC (EMC)
