RK112A-11 10G SFP+ LC Single-mode Transceiver Module with 10Gbps Speed 1310nm Wavelength and 10km Transmission

Large Image : RK112A-11 10G SFP+ LC Single-mode Transceiver Module with 10Gbps Speed 1310nm Wavelength and 10km Transmission

Product Details:

Place of Origin:	China
Brand Name:	Siemens
Certification:	CE
Model Number:	RK112A-11

Payment & Shipping Terms:

Minimum Order Quantity:	1
Delivery Time:	2-3 days
Payment Terms:	T/T

Contact Now

RK112A-11 10G SFP+ LC Single-mode Transceiver Module with 10Gbps Speed 1310nm Wavelength and 10km Transmission

Description

Product Name:	PLC Industrial Control	Part Number:	RK112A-11
Shipment:	DHL	Condition:	New
Lead Time:	2-3 Days	Warranty:	1 Year
Keywords:	RK112A-11
Highlight:	10G SFP+ transceiver module LC single-mode , SFP+ transceiver module 1310nm 10km , 10G SFP+ transceiver module with DOM

Siemens RK112A-11 Overview

The RK112A-11 10G SFP+ LC Single-mode Transceiver Module (1310nm, 10km, DOM) is a high-performance, cost-effective optical transceiver designed for 10 Gigabit Ethernet and fiber channel applications. Compliant with SFF-8431 and SFF-8472 industry standards, it delivers reliable data transmission at a rate of 9.953–10.3125 Gbps over 10km of single-mode fiber (SMF, G.652) with a center wavelength of 1310nm.

Figure 1 shows the front panel of RK112A-11.

Quick Specs.

Table 1 shows the Quick Specs.

Item	Specification
Form Factor	SFP+
Data Rate	10Gbps
Wavelength	1310nm
Transmission Distance	10km (single-mode fiber)
Connector Type	LC duplex
Digital Monitoring	DOM (Digital Optical Monitoring) supported

Detailed Specification

Parameter Category	Parameter Name	Specification
Optical Parameters	Center Wavelength	1310nm ±20nm
	Minimum Transmit Power	-8.5 dBm
	Maximum Transmit Power	-1.5 dBm
	Receive Sensitivity	-17 dBm (max)
	Link Distance	10km (SMF, G.652)
Electrical Parameters	Data Rate Range	9.953 - 10.3125 Gbps
	Power Supply Voltage	3.3V ±5%
	Power Consumption	≤1.2W
Mechanical & Environmental	Form Factor	SFP+ (Compliant with SFF-8431, SFF-8472)
	Connector Type	LC duplex (unplated)
	Operating Temperature	0°C ~ 70°C (Commercial Grade)
	Storage Temperature	-40°C ~ 85°C
Functional Features	Digital Optical Monitoring (DOM)	Yes (supports real-time parameter monitoring)
	Compliance Standards	RoHS, CE, FCC
