SGMG-05A2AB 500W 200VAC 3-Phase AC Servo Motor with 17-Bit Absolute Encoder (IP65 Protection)

Large Image : SGMG-05A2AB 500W 200VAC 3-Phase AC Servo Motor with 17-Bit Absolute Encoder (IP65 Protection)

Product Details:

Place of Origin:	China
Brand Name:	Siemens
Certification:	CE
Model Number:	SGMG-05A2AB

Payment & Shipping Terms:

Minimum Order Quantity:	1
Delivery Time:	2-3 days
Payment Terms:	T/T

Contact Now

SGMG-05A2AB 500W 200VAC 3-Phase AC Servo Motor with 17-Bit Absolute Encoder (IP65 Protection)

Description

Product Name:	PLC Industrial Control	Part Number:	SGMG-05A2AB
Shipment:	DHL	Condition:	New
Lead Time:	2-3 Days	Warranty:	1 Year
Keywords:	SGMG-05A2AB
Highlight:	500W 3-phase AC servo motor , 200VAC servo motor with encoder , IP65 protected industrial servo motor

Siemens SGMG-05A2AB Overview

The SGMG-05A2AB is a high-performance 500W 3-phase AC servo motor engineered for precision industrial motion control applications. Operating at 200VAC, this compact and reliable motor delivers a rated torque of 1.59 N·m and a maximum speed of 6000 rpm, making it ideal for automated production lines, CNC machinery, robotic arms, and other equipment requiring accurate speed and position regulation.

Figure 1 shows the front panel of SGMG-05A2AB.

Quick Specs.

Table 1 shows the Quick Specs.

Parameter	Value
Rated Power	500W
Rated Voltage	200VAC
Rated Speed	3000 rpm
Rated Torque	1.59 N·m
Insulation Class	Class B

Detailed Specification

Parameter	Specification
Model Number	SGMG-05A2AB
Motor Type	AC Servo Motor
Rated Output Power	500W
Rated Input Voltage	200V 3-phase AC
Rated Current	3.0 A
Rated Rotational Speed	3000 rpm
Rated Torque	1.59 N·m
Maximum Torque	4.77 N·m (300% of rated)
Maximum Speed	6000 rpm
Rotor Inertia	0.85 × 10⁻⁴ kg·m²
Weight	Approx. 4.0 kg
Frame Size	80 mm
Insulation Class	Class B (130°C max)
Protection Class	IP65 (shaft seal: IP67)
Cooling Method	Self-cooling
Encoder Type	17-bit Absolute Encoder
