Software compatibility
|
● Cisco Collaboration Endpoint Software Version 9.14.5 or later, and Cisco Webex RoomOS
|
|
Optional hardware components
|
● HDMI presentation cable 8 m/26.2 ft
● 4 m/13 ft USB cable for USB pass-through feature
● Screen Mount Kit
|
|
Bandwidth
|
● Up to 6 Mbps point to point
|
|
Minimum bandwidth for resolution/frame rate
|
H.264:
● 720p30 from 768 kbps
● 720p60 from 1152 kbps
● 1080p30 from 1472 kbps
● 1080p60 from 2560 kbps
|
|
Firewall traversal
|
● Cisco Expressway™ technology
● H.460.18, H.460.19 firewall traversal
|
|
Video standards
|
● H.264
|
|
Video inputs
|
● One HDMI input supports formats up to maximum 4K (3840 x 2160) at 30 fps, including HD1080p60
● Consumer Electronics Control (CEC) 2.0
|
|
Video outputs
|
● 1 HDMI output supports formats up to 3840 x 2160p60 (4Kp60)
● Live video resolutions (encode and decode) up to 1920 x 1080p30 and p60 (HD1080p)
● Consumer Electronics Control (CEC) 2.0
|
|
Audio standards
|
● G.711, G.722, G.722.1, G.729, AAC-LD, and Opus
|
|
Audio features
|
● High-quality 20 kHz audio
● Automatic Gain Control (AGC)
● Automatic noise reduction
● Active lip synchronization
|
|
Audio inputs
|
● One audio in from HDMI
● Internal microphones
● Bluetooth ® - Not available on Non Radio Version *
|
|
Speakers (integrated)
|
● High-quality speakers: full range speaker plus dual woofers in balanced configuration
● Frequency response 100 Hz to 20 kHz
● Amplifier power: 24W
● Max output level SPL 84 dB
|
|
MultiSite
|
● H.239 (H.323) dual stream
● Binary Floor Control Protocol (BFCP) (SIP) dual stream
● Supports resolutions up to 3840 x 2160p5
|
|
Dual stream
|
● One HDMI input supports formats up to maximum 4K (3840 x 2160) at 30 fps, including HD1080p60
● Consumer Electronics Control (CEC) 2.0
|
|
Wireless sharing
|
● Webex app (up to 3840 x 2160p5)
● Cisco Intelligent Proximity client (up to 1920 x 1080p5)
● Miracast (1080p30) – Not available on Non radio version
|
|
Multipoint support
|
● 4-way embedded SIP/H.323 conferencing capability with MultiSite option
|
|
MultiSite features (embedded multipoint)*
|
● Adaptive SIP/H.323 MultiSite:
◦ 3-way resolution up to 1080p30 + content up to 1080p15
◦ 4-way resolution up to 720p30 + content up to 1080p15
● Full individual audio and video transcoding
● H.323/SIP/VoIP in the same conference
● Support for presentation (H.239/BFCP) from any participant at resolutions up to 3840 x 2160p5
● Best impression (automatic continuous presence layouts)
● Encryption and dual stream from any site
|
|
Protocols
|
● H.323
● SIP
● Cisco Webex
|
|
Embedded encryption
|
● H.323 and SIP point to point
● Standards-based: H.235 v3 and Advanced Encryption Standard (AES)
● Automatic key generation and exchange
|
|
IP network features
|
● DNS lookup for service configuration
● Differentiated services (Quality of Service [QoS])
● IP-adaptive bandwidth management (including flow control)
● Automatic gatekeeper discovery
● Dynamic playout and lip-sync buffering
● H.245 Dual-Tone Multifrequency (DTMF) tones in H.323
● RFC 4733 DTMF tones in SIP
● Date and time support using Network Time Protocol (NTP)
● Media adaptation and resilience
● Uniform Resource Identifier (URI) dialing
● Dynamic Host Configuration Protocol (DHCP)
● 802.1X network authentication
● 802.1Q Virtual LAN
● 802.1p (QoS and Class of Service [CoS])
|
|
Call control
|
● Cisco Unified Communications Manager (Unified CM)
◦ Native registration with Unified CM
◦ Requires Unified CM Version 9.1(2) or later with device pack Room Kit Mini
● Cisco Expressway
◦ Native registration with Expressway
● Cisco Webex Service
● Third-party H.323 gatekeepers and standards-based SIP proxies
|
|
IPv6 network support
|
● Single call stack support for both H.323 and SIP
● Dual-stack IPv4 and IPv6 for DHCP, SSH, HTTP, HTTPS, DNS, DiffServ
● Support for both static and automatic IP configuration (stateless address auto configuration)
|
|
Security features
|
● Management using HTTPS and SSH
● IP administration password
● Menu administration password
● Disable IP services
● Network settings protection
● Privacy cover
|
|
Network interfaces
|
● One Ethernet (RJ-45) 10/100/1000 for LAN
● One Ethernet (RJ-45) for Cisco Touch 10 direct pairing
● Wi-Fi 802.11a/b/g/n/ac 2.4 GHz/5 GHz - not available in non-radio versions
Note: Due to compliance regulations, it is required that 802.11d is enabled in the access point for the product to operate properly within 5725 MHz – 5875 MHz.
Using a Wi-Fi connection is a flexible option, however an Ethernet connection is always preferred for high performance.
|
|
USB passthrough
|
● Ability to join any web conferencing service and share content using the camera, microphones and speakers of Room Kit Mini with a USB cable connected with the external monitor and an HDMI cable connected with the computer
● 720p video resolution
|
|
Other interfaces
|
● 1 USB 2.0 port type A
● 1 USB 2.0 port type C
● 1 USB port
● Factory reset pinhole
|
|
Power
|
● 100 to 240 VAC, 50/60 Hz, 12V DC input
● Average 20W, peak 70W
● Must be used with power supply FSP FSP070-AHAN2 or AcBel ADF019
|
|
Operating temperature and humidity
|
● 0°C to 35°C (32°F to 104°F) ambient temperature
● 10% to 90% Relative Humidity (RH)
|
|
Storage and transport temperature
|
● -20°C to 60°C (-4°F to 140°F) at RH 10% to 90% (non condensing)
|
|
Dimensions
|
● Width: 19.7 in. (50.0 cm)
● Height: 3.2 in. (8.1 cm)
● Depth: 3 in. (7.7 cm)
● Weight: 4 lb. (2 kg)
Packaging size
● Width: 23.8 in. (60.5 cm)
● Height: 12.8 in. (32.6 cm)
● Depth: 8.5 in. (21.6 cm)
● Weight: 7 lb. (3.2 kg)
|
|
Camera overview
|
● 4K UltraHD camera
● Supports up to 30 fps
● 8 MP image sensor
● 1/2.5’’ CMOS
● 5x zoom
● f/1.4 aperture
● 120° horizontal field of view
● Auto framing (face detect)
● Best overview
● Auto brightness, and white balance
● Focus distance 1 m to infinity
|
