WS-C3650-48FS-S Specification
|
|
Enclosure type
|
Rack-mountable - 1U
|
|
Ports
|
48 x 10/100/1000 (POE+) + 4 x 1G SFP
|
|
Network management Interface
|
• Ethernet management port: RJ-45 connectors, 4-pair Cat-5 UTP cabling
• Management console port: RJ-45-to-DB9 cable for PC connections
|
|
Available PoE Power
|
775W
|
|
Switching Capacity
|
176Gbps
|
|
Maximum stacking number
|
9
|
|
Stack Bandwidth
|
160Gbps
|
|
Forwarding Performance
|
77.37Mpps
|
|
FNF entries
|
48000
|
|
Maximum VLANs IDs
|
4,094
|
|
MAC Address Table Size
|
32K
|
|
CPU
|
Multicore CPU
|
|
RAM
|
4 G
|
|
Flash Memory
|
2 G
|
|
Wireless
|
|
Number of AP per switch/stack
|
50
|
|
Number of wireless clients per switch/stack
|
1000
|
|
Total number of WLANs per switch
|
64
|
|
Wireless bandwidth per switch
|
up to 40Gbps
|
|
Supported Aironet AP series
|
3700, 3600, 3500, 2600, 1600, 1260, 1140, 1040
|
|
Expansion / Connectivity
|
|
Console ports
|
USB (Type-B), Ethernet (RJ-45)
|
|
Expansion Slot(s)
|
power redundant slot
|
|
Accessory & Rack Moubt Kits
|
• ACC-KIT-T1: Accessory kit
• RACK-KIT-T1: Rack mount kit
• 4PT-KIT-T1:Extension rails and brackets for four-point mounting
|
|
Stacking module & cable
|
• C3650-STACK-KIT: Stack Module
• STACK-T2-50CM: StackWise-160 stacking cable with a 0.5 m length
• STACK-T2-1M: StackWise-160 stacking cable with a 1.0 m length
• STACK-T2-3M: StackWise-160 stacking cable with a 3.0 m length
|
|
Power supply
|
PWR-C2-1025WAC
|
|
Power Device
|
Power supply - redundant - plug-in module
|
|
Power Redundancy
|
optional
|
|
Voltage range (Auto)
|
100V-240V
|
|
Power Consumption of standalone (in Watts)
|
109.4 (max)
|
|
Miscellaneous
|
|
Width
|
17.5 Inches (44.5 cm)
|
|
Depth
|
19.125 Inches (48.6 cm)
|
|
Height
|
1.73 Inches (4.4 cm)
|
|
Shipping Weight
|
17.49 Kg
|
|
Rack Mounting Kit
|
optional
|
|
MTBF in hours
|
383,760
|
|
Compliant Standards
|
• IEEE 802.1D Spanning Tree Protoco
• IEEE 802.1p CoS Prioritization
• IEEE 802.1Q VLAN
• IEEE 802.1s
• IEEE 802.1w
• IEEE 802.1X
• IEEE 802.1X-Rev
• IEEE 802.11
• IEEE 802.1ab (LLDP)
• IEEE 802.3ad
• IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports
• IEEE 802.3 10BASE-T
• IEEE 802.3u 100BASE-TX
• IEEE 802.3ab 1000BASE-T
• IEEE 802.3z 1000BASE-X
• RMON I and II standards
• SNMP v1, v2c, and v3
|
|
System software / license
|
|
System software
|
IOS IP Base (Upgradable)
|
|
EnergyWise license
|
ENERGY-MGMT, ENERGY-MGT-100-K9
|
|
Software license
|
• C3650-48-S-E: IP Base to IP Services RTU paper license
• L-C3650-48-S-E: IP Base to IP Services RTU electronic license
|
|
Access Point Licenses
|
• L-LIC-CT3650-UPG: Primary upgrade license SKU for Cisco 3650 wireless controller (e-delivery)
• L-LIC-CTIOS-1A: 1 access point adder license for Cisco IOS Software based wireless controller (e-delivery)
• L-LIC-CTIOS-1A: 1 access point adder license for Cisco IOS Software based wireless controller (e-delivery)
• LIC-CTIOS-1A: 1 access point adder license for the Cisco IOS Software based wireless controller (paper license)
|
|
Features
|
• EEM • RPS Support • IP service-level agreements (SLAs) • Advanced IP unicast routing protocols
• Jumbo Frames • VLANS • Voice Vlan • VTPv2 • CDPv2 • LLDP • 802.3ad LACP and PAgP • PVST/PVST+
• 802.1W/802.1S • Port Fast/Uplink Fast • Dynamic Trunking Protocol (DTP) • port CoS Trust and Override
• Trusted Boundary • ACL Classification • ingress Policing • Auto QoS • Per VLAN policies • 802.1p queues
• Scheduling • Priority Queuing • Configure CoS Priority Queues • Configure CoS Priority Queues
• Configure Queue Weights • Configure Buffers and Thresholds • Class & Policy Maps • Modify CoS and DSCP Mapping
• Weighted Tail Drop • IGMPv1,v2,v3 and MLDv1, v2 • DHCP server • DSCP transparency • HSRP, VRRP, BLGP
• RIPv1, v2 EIGRP, PIM OSPF, OSPFv3, EIGRPv6, BGPv4, IS-ISv4 • VRF-lite • PIM-SM/DM, PIM sparse-dense
mode, SSM • Flexible Netflow
|
|
Advanced Network security
|
• Port security • DHCP snooping • Dynamic ARP inspection (DAI) • IP source guard
• The Unicast Reverse Path Forwarding (uRPF)
• Bidirectional data support on a SPAN • User authentication
• Private VLAN • Router and VLAN ACLs • complete identity and security
• Multidomain authentication • MAC address notification
• IGMP filtering • Cisco security VLAN ACL
• Secure Shell (SSH) Protocol, Kerberos, and Simple Network Management Protocol Version 3 (SNMPv3)
• Port-based ACLs • TrustSec SXP • IEEE 802.1ae
• TACACS+ and RADIUS authentication • Cisco standard and extended IP security router ACLs
• Bridge protocol data unit (BPDU) Guard
• Spanning Tree Root Guard (STRG) • Wireless end-to-end security
|
|
Management
|
• BRIDGE-MIB • CISCO-AUTH-FRAMEWORK-MIB
• CISCO-BGP4-MIB, BGP4-MIB • CISCO-BRIDGE-EXT-MIB
• CISCO-BULK-FILE-MIB • CISCO-CABLE-DIAG-MIB
• CISCO-CALLHOME-MIB • CISCO-CEF-MIB
• CISCO-CIRCUIT-INTERFACE-MIB
• CISCO-ENTITY-VENDORTYPE-OID-MIB
• CISCO-CONTEXT-MAPPING-MIB
• CISCO-DEVICE-LOCATION-MIB • CISCO-DHCP-SNOOPING-MIB
• CISCO-EIGRP-MIB
• CISCO-EMBEDDED-EVENT-MGR-MIB
• CISCO-ENTITY-FRU-CONTROL-MIB • CISCO-ENTITY-SENSOR-MIB
• ENTITY-MIB • CISCO-ERR-DISABLE-MIB
• CISCO-CONFIG-COPY-MIB • CISCO-FLOW-MONITOR-MIB
• CISCO-FTP-CLIENT-MIB • CISCO-HSRP-EXT-MIB
• CISCO-HSRP-MIB • CISCO-IETF-ISIS-MIB
• CISCO-IF-EXTENSION-MIB • CISCO-IGMP-FILTER-MIB
• CISCO-CONFIG-MAN-MIB • CISCO-IP-CBR-METRICS-MIB
• CISCO-IPMROUTE-MIB • CISCO-IP-STAT-MIB
• CISCO-IP-URPF-MIB • CISCO-L2L3-INTERFACE-CONFIG-MIB
• CISCO-LAG-MIB • CISCO-LICENSE-MGMT-MIB
• CISCO-MAC-AUTH-BYPASS-MIB • CISCO-MAC-NOTIFICATION-MIB
• CISCO-MDI-METRICS-MIB • CISCO-FLASH-MIB • CISCO-OSPF-MIB
• CISCO-OSPF-TRAP-MIB • CISCO-PAE-MIB • CISCO-PAGP-MIB
• CISCO-PIM-MIB • CISCO-PING-MIB • CISCO-PORT-QOS-MIB
• CISCO-PORT-SECURITY-MIB• CISCO-PORT-STORM-CONTROL-MIB
• CISCO-POWER-ETHERNET-EXT-MIB • CISCO-PRIVATE-VLAN-MIB
• CISCO-PROCESS-MIB • CISCO-PRODUCTS-MIB• CISCO-RF-MIB
• CISCO-RTP-METRICS-MIB • CISCO-RTTMON-MIB
• CISCO-SMART-INSTALL-MIB
• CISCO-SNMP-TARGET-EXT-MIB • CISCO-STACKMAKER-MIB
• CISCO-MEMORY-POOL-MIB • CISCO-STP-EXTENSIONS-MIB
• CISCO-SYSLOG-MIB • CISCO-TCP-MIB • CISCO-UDLDP-MIB
• CISCO-VLAN-IFTABLE-RELATIONSHIP-MIB • CISCO-VLAN-MEMBERSHIP-MIB
• CISCO-VTP-MIB • EtherLike-MIB
• HC-RMON-MIB • IEEE8021-PAE-MIB • IEEE8023-LAG-MIB
• IF-MIB • IGMP-MIB • IGMP-STD-MIB • IP-FORWARD-MIB
• IP-MIB • IPMROUTE-STD-MIB • LLDP-EXT-MED-MIB
• LLDP-MIB • NOTIFICATION-LOG-MIB
• OLD-CISCO-MEMORY-MIB • CISCO-CDP-MIB
• POWER-ETHERNET-MIB • RMON2-MIB
• RMON-MIB • SNMP-COMMUNITY-MIB • SNMP-FRAMEWORK-MIB
• SNMP-MPD-MIB • SNMP-NOTIFICATION-MIB • SNMP-PROXY-MIB
• SNMP-TARGET-MIB • SNMP-USM-MIB • SNMPv2-MIB
• SNMP-VIEW-BASED-ACM-MIB • TCP-MIB • UDP-MIB
• CISCO-IMAGE-MIB • CISCO-STACKWISE-MIB
• AIRESPMACE-WIRELESS-MIB • CISCO-LWAPP-IDS-MIB
• CISCO-LWAPP-AP-MIB • CISCO-LWAPP-CCX-RM-MIB
• CISCO-LWAPP-CLIENT-ROAMING-MIB
• CISCO-LWAPP-DOT11-CCX-CLIENT-DIAG-MIB
• CISCO-LWAPP-DOT11-CCX-CLIENT-MIB
• CISCO-LWAPP-DOT11-CLIENT-CCX-REPORTS-MIB
• CISCO-LWAPP-DOT11-CLIENT-MIB • CISCO-LWAPP-DOT11-MIB
• CISCO-LWAPP-DOWNLOAD-MIB • CISCO-LWAPP-LINKTEST-MIB
• CISCO-LWAPP-MFP-MIB • CISCO-LWAPP-MOBILITY-EXT-MIB
• CISCO-LWAPP-QOS-MIB • CISCO-LWAPP-REAP-MIB
• CISCO-LWAPP-ROGUE-MIB • CISCO-LWAPP-RRM-MIB
• CISCO-LWAPP-SI-MIB • CISCO-LWAPP-TSM-MIB
• CISCO-LWAPP-WLAN-MIB • CISCO-LWAPP-WLAN-SECURITY-MIB
|
|
Technical Support and Services
|
• Cisco SMARTnet Service • Cisco Smart Foundation Service • Cisco SP Base Service
• Cisco Focused Technical Support Services
|
|
Environmental Ranges
|
|
With AC power supply
Operating environment and altitude
|
|
Operating temperature up to 5000 ft (1500 m)
|
23ºF to 113ºF (-5ºC to +45ºC)
|
|
Operating temperature up to 10,000 ft (3000 m)
|
23ºF to 104ºF (-5ºC to +40ºC)
|
|
Short-term exception at sealevel with single fan failure
|
23ºF to 113ºF (-5ºC to +45ºC)
|
|
Short-term exception up to 5000 feet (1500 m)
|
23ºF to 122ºF (-5ºC to 50ºC)
|
|
Short-term exception up to 10,000 feet (3000 m)
|
23ºF to 113ºF (-5ºC to 45ºC)
|
|
With DC power supply
Operating environment and altitude (NEBS)
|
|
Operating temperature up to 6000 ft (1800 m)
|
23ºF to 113ºF (-5ºC to +45ºC)
|
|
Operating temperature up to 10,000 ft (3000 m)
|
23ºF to 104ºF (-5ºC to +40ºC)
|
|
Operating temperature up to 13,000 ft (4000m)
|
23ºF to 95ºF (-5ºC to 35ºC)
|
|
Short-term exception up to 6,000 feet (1800 m)
|
23ºF to 131ºF (-5ºC to +55ºC)
|
|
Short-term exception up to 10,000 feet (3000 m)
|
23ºF to 122ºF (-5ºC to +50ºC)
|
|
Short-term exception up to 13,000 feet (4000 m)
|
23ºF to 113ºF (-5ºC to +45ºC)
|
|
Short-term exception at sealevel with single fan failure
|
23ºF to 113ºF (-5ºC to +45º)
|
|
Storage environment
|
-40ºF to 160ºF (-40ºC to 70ºC)
|
|
Operating altitude
|
Up to 16,400 Feet (Up to 5000m)
|
|
Storage altitude
|
Up to 16,400 Feet (Up to 5000m)
|
|
Operating relative humidity
|
5% to 96% noncondensing
|
|
Storage relative humidity
|
5% to 96% noncondensing
|
|
Short-term exception at sealevel with single fan failure
|
23ºF to 113ºF
|
|
Storage environment
|
-40ºF to 160ºF
|
