Huawei S5720S-52P-PWR-LI-AC 48-Port Gigabit PoE+ Switch with 4 SFP

Large Image : Huawei S5720S-52P-PWR-LI-AC 48-Port Gigabit PoE+ Switch with 4 SFP

Product Details:

Place of Origin:	China
Brand Name:	Huawei
Certification:	CE
Model Number:	S5720S-52P-PWR-LI-AC
Document:	LONRISE EQUIPMENT Company ...le.pdf

Contact Now

Huawei S5720S-52P-PWR-LI-AC 48-Port Gigabit PoE+ Switch with 4 SFP

Description

Model:	S5720S-52P-PWR-LI-AC	Fixed Ports:	48 × 10/100/1000 Base‑T PoE+ Ethernet Ports & 4 × 1000 Base‑X Gigabit SFP Uplink Ports
Forwarding Performance:	87 Mpps	Switching Capacity:	336 Gb/s
Total PoE Budget:	~370 W	RAM:	512 MB
Flash:	240 MB	Dimensions:	442.0 Mm X 310.0 Mm X 43.6 Mm
Weight:	5.9 Kg
Highlight:	Huawei 48-port PoE+ network switch , Gigabit PoE switch with SFP ports , Huawei S5720S switch with warranty

S5720S-52P-PWR-LI-AC 48-Port Gigabit PoE+ Switch

Professional-grade 48-port Ethernet switch with 4 Gigabit SFP uplinks and 370W PoE+ power budget, designed for enterprise networking applications.

Key Features

48 × 10/100/1000Base-T PoE+ Ethernet ports
4 × 1000Base-X Gigabit SFP uplink ports
370W total PoE budget for powering devices
High-performance switching capacity of 336 Gb/s
Compact 1U form factor for space-efficient deployment

Technical Specifications

Attribute	Value
Model	S5720S-52P-PWR-LI-AC
Fixed Ports	48 × 10/100/1000Base-T PoE+ & 4 × 1000Base-X SFP
Forwarding Performance	87 Mpps
Switching Capacity	336 Gb/s
Total PoE Budget	370W
Dimensions (W × D × H)	442.0 × 310.0 × 43.6 mm (17.4 × 12.2 × 1.72 in)
Weight	5.9 kg (13.01 lb)

Detailed Specifications

Memory (RAM)	512 MB
Flash Memory	240 MB
MTBF	38 years
MTTR	2 hours
Availability	> 0.99999
Power Consumption	Maximum: - Without PoE: 61.7 W - 100% PoE loads: 461.8 W (system: 92.2 W, PoE: 369.6 W) Typical (30% load, EEE enabled, no PoE): 42 W
Power Input	100-240V AC, 50/60Hz (90-264V AC operating range)
Operating Temperature	-40°C to +70°C (-40°F to +158°F)
Noise Level	< 48.3 dBA @ 27°C
Operating Humidity	5% to 95% (non-condensing)

All specifications are subject to change without notice. Please verify with manufacturer for latest technical details.
