C9200L-24P-4G-A Catalyst 9200L 24-port PoE+ 4x1G Uplink Switch Network Advantage

Large Image : C9200L-24P-4G-A Catalyst 9200L 24-port PoE+ 4x1G Uplink Switch Network Advantage

Product Details:

Place of Origin:	China
Brand Name:	Cisco
Certification:	CE
Model Number:	C9200L-24P-4G-A
Document:	LONRISE EQUIPMENT Company ...le.pdf

Payment & Shipping Terms:

Minimum Order Quantity:	1 PCS
Delivery Time:	1~3 Days
Payment Terms:	T/T,Western Union

Contact Now

C9200L-24P-4G-A Catalyst 9200L 24-port PoE+ 4x1G Uplink Switch Network Advantage

Description

Product Type:	Fixed Configuration Switch	License Level:	Advanced (A)
Fixed Ports:	24 × 10/100/1000BASE-T (RJ45) With PoE+ Support; 4 × 1G SFP Uplinks	Power Supply:	600W AC (PWR-C5-600WAC Or PWR-C6-600WAC)
Software Licensing:	Advanced (pre-installed)	Input Voltage:	100–240V AC, 50/60Hz
Highlight:	Cisco Catalyst 9200L PoE+ switch , 24-port PoE+ network switch , Cisco C9200L Ethernet switch with warranty

C9200L-24P-4G-A Overview

The Cisco C9200L-24P-4G-A is a robust enterprise-grade switch engineered for advanced, secure, and scalable business networking across diverse environments. Belonging to the renowned Cisco 9200 family, this model leverages a fixed configuration platform to deliver optimal network performance for mid-sized businesses and br

C9200L-24P-4G-A Catalyst 9200L 24-port PoE+ 4x1G Uplink Switch Network Advantage 0

C9200L-24P-4G-A Specification

Model

C9200L-24P-4G-A

Brand

Cisco

Series

Catalyst 9200L Series

Product Type

Fixed Configuration Switch

License Level

Advanced (A)

Chassis Dimensions (H×W×D)

Base Unit: 1.73 × 17.5 × 11.3 in (4.4 × 44.5 × 28.8 cm); With FEP/Fan: 1.73 × 17.5 × 12.9 in (4.4 × 44.5 × 32.9 cm)

Fixed Ports

24 × 10/100/1000BASE-T (RJ45) with PoE+ support; 4 × 1G SFP uplinks

PoE Budget

370W total PoE power, supports 802.3af/at PoE+

Power Supply

600W AC (PWR-C5-600WAC or PWR-C6-600WAC)

Input Voltage

100–240V AC, 50/60Hz

Switching Capacity

96 Gbps

Forwarding Rate

72 Mpps

Buffer Memory

16 MB shared

MAC Address Table

32,000 entries

VLAN Support

4,096 active VLANs, 1,500 STP instances

MTBF

392,210 hours (~44.8 years)

Software Licensing

Advanced (pre-installed)

Minimum IOS-XE

16.12.1

Layer 3 Routing

OSPF, EIGRP, BGP, IS-IS, PIM, VRF-lite

Security Features

802.1X, MACsec, TrustSec, Flexible NetFlow, sFlow

Environmental - Operating Temperature

Standard: 32°F to 104°F (0°C to 40°C), Short-term: -5°C to 50°C (up to 96 hours/year)

Environmental - Humidity

5% to 90% non-condensing

Environmental - Altitude

Up to 10,000 ft (3,000 m)

Acoustics

Noise Level (25°C): LpA 42 dB typical, 45 dB max; LwA 5.3 B typical, 5.6 B max

Management Interfaces

1 × RJ45 console (10/100), 1 × RJ45 management (10/100)

Supported Protocols

SNMPv3, NETCONF/YANG, RESTCONF, gRPC

Compliance - Safety

UL 60950-1, EN 62368-1

Compliance - EMC

FCC Part 15 Class A, EN 55032

Compliance - RoHS

Compliant

Power Consumption (with PoE)

115V AC: Idle 38.95W, 50% 44.08W, 100% 49.00W; 230V AC: Idle 38.57W, 50% 43.69W, 100% 48.62W
