AR1220C S Huawei AR1200 Router Detail Huawei AR1220C 8GE LAN 5GE WAN 2 USB 2 SIC Is The Next Generation Enterpriseclass Router

Large Image : AR1220C S Huawei AR1200 Router Detail Huawei AR1220C 8GE LAN 5GE WAN 2 USB 2 SIC Is The Next Generation Enterpriseclass Router

Product Details:

Place of Origin:	CHINA
Brand Name:	Huawei
Certification:	CE
Model Number:	AR1220C S

Contact Now

AR1220C S Huawei AR1200 Router Detail Huawei AR1220C 8GE LAN 5GE WAN 2 USB 2 SIC Is The Next Generation Enterpriseclass Router

Description

Name:	AR1220C S	Model:	AR1220C S Huawei AR1200 Router
Rack Units:	3U	Interfaces:	LAN Interfaces: GE0-GE7
Warrranty:	1 Year	Shipping:	DHL&FeDex
Product Type:	Router	Power Module Type:	Built-in AC Power Module
Dimensions (W X D X H):	44.5 Mm X 390 Mm X 220 Mm
Highlight:	5GE WAN Huawei AR1220C S , Huawei AR1220C S , 2 USB Huawei AR1220C S

AR1220C-S Overview

Huawei AR1200C-S is the next generation enterprise-class router, the router based on the Huawei proprietary Versatile Routing Platform which is built on Huawei.

Quick Specs

Figure 1 shows the appearance of AR1220C-S.

AR1220C S Huawei AR1200 Router Detail Huawei AR1220C 8GE LAN 5GE WAN 2 USB 2 SIC Is The Next Generation Enterpriseclass Router 0

Table 1 shows the Quick Specs.

Product Code	Huawei Router - AR1220C-S
Memory	512 MB
Flash	512 MB
Service interfaces (standard configuration)	WAN interfaces: 2 GE combo interfaces LAN interfaces: 8 10/100/1000M auto-sensing Ethernet electrical interfaces
Extended slots	2 SIC slots
Interface number	LAN interfaces: GE0-GE7
Power module type	Built-in AC power module
Dimensions (W x D x H)	44.5 mm x 390 mm x 220 mm

Product Details

Figure 2 shows the front panel of AR1220C-S.

Note:

①	Two USB interfaces (host)
②	RST button

Figure 3 shows the back panel of AR1220C-S.

Note:

①	Two SIC slots	⑥	LAN interfaces: eight GE electrical interfaces
②	Product model silkscreen	⑦	WAN interface: GE electrical interface
③	Ground point	⑧	Mini USB interface
④	Jack for power cable locking strap	⑨	CONSOLE interface
⑤	AC power jack	⑩	WAN interface: GE optical interface

The Optical transceiver, Cards

Table 2 shows the recommended elements for the Huawei Router - AR1220C-S.

Model	Description
FE-SFP Optical Transceiver
SFP-FE-SX-MM1310	SFP,100M/155M,Multi-mode Module(1310nm,2km,LC)
eSFP-FE-LX-SM1310	eSFP,100M/155M,Single-mode Module(1310nm,15km,LC)
S-SFP-FE-LH40-SM1310	eSFP,FE,Single-mode Module(1310nm,40km,LC)
GE-SFP Optical Transceiver
SFP-1000BaseT	SFP,GE,Electrical Interface Module(100m,RJ45)
eSFP-GE-SX-MM850	eSFP,GE,Multi-mode Module(850nm,0.55km,LC)
SFP-GE-LX-SM1310	eSFP,GE,Single-mode Module(1310nm,10km,LC)
S-SFP-GE-LH40-SM1310	eSFP,GE,Single-mode Module(1310nm,40km,LC)
S-SFP-GE-LH40-SM1550	eSFP,GE,Single-mode Module(1550nm,40km,LC)
WAN interface card
AR-1E3T3M-W	1-Port Channelized/Unchannelized E3/T3 WAN Interface Card
xDSL interface card
AR01SLV1XA	1-Port VDSL2 over POTS WAN Interface Module

Compare to Similar Items

Table 3 shows the comparison between AR1220C-S and AR0M012VBA00.

Model	AR1220C-S	AR0M012VBA00
WAN Speed with Services	200 Mbit/s	200 Mbit/s
Fixed WAN Ports	2 x GE Combo	2 x GE
Fixed LAN Ports	8 x GE (can be configured as WAN interfaces)	8 x FE (can be configured as WAN interfaces)
Slots	SIC slots: 2 WSIC slots (default/max): 0/1
Memory	512 GB	512 MB

Green	Present and enabled.
Amber	Present with failure.

AR1220C S Huawei AR1200 Router Detail Huawei AR1220C 8GE LAN 5GE WAN 2 USB 2 SIC Is The Next Generation Enterpriseclass Router 1
