Product Details:
|
| Model: | N9K-C93180YC-FX2 | Switching Capacity: | 176 GbpsN9K-C93180YC-FX3 |
|---|---|---|---|
| Forwarding Rate: | 261.9 Mpps | Port Type: | 8xmGig PoE+ |
| Flash Memory: | 16 GBN9K-C93180YC-FX3 | DRAM: | 4 GBN9K-C93180YC-FX3 |
| Chassis Dimensions: | 1.73 X 17.5 X 13.8 In | Condition: | New Factory Sealed |
| Warranty: | 1 Year N9K-C93180YC-FX3 | Payment: | T/T, Western Union, Paypal |
| Shipment: | DHL, Fedex, UPS | ||
| Highlight: | Network Essentials Cisco Switch,8xmGig PoE+ Cisco Switch,24-port Cisco Switch |
||
The Cisco N9K-C93180YC-FX3 is a cutting-edge product in the Cisco Nexus 9000 Switches series. It is designed to meet the needs of modern data centers and provide high-performance and reliable networking solutions. With its advanced features and robust design, this switch is a game-changer in the world of networking.
N9K-C93180YC-FX3 Specification |
|
| Feature | Cisco Nexus 93180YC-FX3 |
| Ports |
Downlinks: 48 x 1/10/25G SFP28 ports Uplinks: 6 x 40/100G QSFP28 ports |
| CPU | 4 cores |
| System memory |
Default: 16GB Expandable: 16GB |
| SSD drive | 128 GB |
| System buffer | 40 MB |
| Management ports | 1 port: 1 RJ-45 |
| USB ports | 1 |
| 1PPS | GPS 1PPS input or output |
| 10MhZ | GPS 10Mhz input or output. |
| Time of Day (ToD) | 1 RJ-45 |
| ANT | Antenna for GNSS |
| RS-232 serial ports | 1 |
| Power supplies (up to 2) |
650W AC port-side intake and port-side exhaust 930W DC port-side intake and port-side exhaust 1200W HVAC/HVDC dual direction |
| Typical power (AC/DC) | 325W |
| Maximum power (AC/DC) | 600W |
| Input voltage (AC) | 100 to 240V |
| Input voltage (High-Voltage AC [HVAC]) |
200 to 277V |
| Input voltage (DC) | –48 to –60V |
| Input voltage (High-Voltage DC [HVDC]) |
–240 to –380V |
| POE Ports | NA |
| POE Modes | NA |
| Frequency (AC) | 50 to 60 Hz |
| Fans | 4 |
| Airflow | Port-side intake and exhaust |
| Physical dimensions (H x W x D) |
1.72 x 17.3 x 19.6 in. (4.4 x 43.9 x 49.6 cm) |
| Acoustics |
Port-side exhaust: Fan speed at 50%:63.4 dBA Fan speed at 70%:74.3 dBA Fan speed at 100%: 83.4 dBA Port-side intake: Fan speed at 50%:64.6 dBA Fan speed at 70%:76.1 dBA Fan speed at 100%: 85.4 dBA |
| RoHS compliance | Yes |
| MTBF | 288,760 Hours |
| Minimum ACI release | ACI-15.1.3 |
| Minimum NX-OS release | NXOS-9.3.7 |
