Product Details:
|
| Model: | N9K-C93180YC-EX | Switching Capacity: | 176 Gbps |
|---|---|---|---|
| Forwarding Rate: | 261.9 Mpps | Port Type: | 8xmGig PoE+ |
| Flash Memory: | 16 GBN9K-C93180YC-EX | DRAM: | 4 GBN9K-C93180YC-EX |
| Chassis Dimensions: | 1.73 X 17.5 X 13.8 In | Condition: | New Factory Sealed |
| Warranty: | 1 Year N9K-C93180YC-EX | Payment: | T/T, Western Union, Paypal |
| Shipment: | DHL, Fedex, UPS | ||
| Highlight: | 8xmGig PoE+ Cisco Switch,N9K-C93180YC-EX Cisco Switch,24-port Cisco Switch |
||
N9K-C93180YC-EX is one of the Cisco Nexus 9300-EX switches. Cisco Nexus 9300-EX platforms are the next generation of fixed Cisco Nexus 9000 Series Switches. The new platforms support cost-effective cloud-scale deployments, an increased number of endpoints, and cloud services with wire-rate security and telemetry. The platforms are built on modern system architecture designed to provide high performance and meet the evolving needs of highly scalable data centers and growing enterprises.
| Part Number | N9K-C93180YC-EX |
| Ports | 48 x 10/25-Gbps and 6 x 40/100-Gbps QSFP28 ports |
| Downlink supported speeds | 1/10/25-Gbps speeds |
| CPU | 4 cores |
| System memory | 24 GB |
| SSD drive | 64 GB |
| System buffer | 40 MB |
| Management ports | 2 ports: 1 RJ-45 and 1 SFP |
| USB ports | 1 |
| RS-232 serial ports | 1 |
| Power supplies (up to 2) | 650W AC, 930W DC, or 1200W HVAC/HVDC |
| Typical power (AC/DC) | 210W |
| Maximum power (AC/DC) | 470W |
|
Physical dimensions (H x W x D) |
1.72 x 17.3 x 22.5 in. (4.4 x 43.9 x 57.1 cm) |
| Weight (without power supplies or fans) | 17.2 lb (7.8 kg) |
