Product Details:
|
| Model: | N9K-C9372TX-E | Switching Capacity: | 176 Gbps |
|---|---|---|---|
| Forwarding Rate: | 261.9 Mpps | Port Type: | 8xmGig PoE+ |
| Flash Memory: | 16 GB N9K-C9372TX-E | DRAM: | 4 GB N9K-C9372TX-E |
| Chassis Dimensions: | 1.73 X 17.5 X 13.8 In | Condition: | New Factory Sealed |
| Warranty: | 1 Year N9K-C9372TX-E | Payment: | T/T, Western Union, Paypal |
| Shipment: | DHL, Fedex, UPS | ||
| Highlight: | Cisco Switch Catalyst 9200 Switch,Catalyst 9200 Cisco Ethernet Switch |
||
The Cisco Nexus 9372TX-E Switch (N9K-C9372TX-E) is a minor hardware revision of the Cisco Nexus 9372TX. Enhancements include hardware capability for IP-based EPG classification in Cisco ACI mode.
| Product Code | N9K-C9372TX-E |
| Ports | 48 fixed 1/10GBASE-T and 6 QSFP+ ports |
| Form factor | 1 RU |
| Throughput (Tbps) | 1.44 |
| Supported speeds | 100 Megabit Ethernet and 1/10 Gigabit Ethernet speeds |
| 40 Gigabit Ethernet uplink port |
6 fixed QSFP+ ports ·Advanced QSFP+ optics enable connectivity using existing 10 Gigabit Ethernet fiber.·The switch offers 25 MB of additional packet buffer space shared with all ports for more resilient operations |
| Power supplies (up to 2) | 650W AC, 930W DC, or 1200W HVAC/HVDC |
| Typical power(AC & DC) | 374.5W |
| Maximum power(AC & DC) | 694W |
| Maximum number of longest prefix match (LPM) routes | 128,000 |
| CPU, SSD, and memory | Dual-core 2.5-GHz x86 CPUs with 64-GB SSD drive and 16 GB of memory provide enhanced network performance |
| Buffer (MB) | 37 |
| Operating System | NX-OS, ACI |
| Fans | 4 |
| Physical (H x W x D) | 1.72 x 17.3 x 22.5 in. (4.4 x 43.9 x 57.1cm) |
| Acoustics | 48.6 dBA at 40% fan speed, 65.2 dBA at 70% fan speed, and 76.5 dB at 100% fan speed |
| Weight(without power supplies or fans) | 22.6 lb (10.25 kg) |
