Product Details:
|
| Model: | OSX040N01 | Transceiver Form Factor: | SFP+ |
|---|---|---|---|
| Transmission Speed: | 10 Gbit/s | Center Wavelength (nm): | 1550mm |
| Connector Type: | LC | Optical Fiber Type: | SMF |
| Single-mode Fiber: | 40 Km | Condition: | New Factory Sealed |
| Warranty: | 1 Year | Shipment: | DHL, Fedex, UPS |
| Payment: | T/T, Western Union, Paypal | ||
| Highlight: | 10G Huawei Optical Transceiver,40km Huawei Optical Transceiver,LC Huawei Optical Transceiver |
||
Huawei's OSX040N01 is a high-performance SFP+ module designed for 10G Ethernet applications. With a single-mode, 1550nm wavelength and a transmission distance of 40km, this module provides reliable and high-speed connectivity. The LC interface ensures easy and secure plug-and-play installation.
Table 1: Quick Spec of OSX040N01
| Module Type | SFP+ |
| Data Rate | 10G |
| Transmission Mode | Single-mode |
| Wavelength | 1550nm |
| Connector type | LC |
OSX040N01 Specifications |
|
| Product Model | OSX040N01 |
| Brand | Huawei |
| Form factor | SFP+ |
| Data Rate | 10G |
| Transmission Medium | Single-mode |
| Wavelength | 1550nm |
| DDM options | Supported |
| Connector Type | LC |
| Operating Temperature | 0°C to 70°C (32°F to 158°F) |
| Diagnostics Monitoring | Supported |
| Optical Interface | Duplex LC |
| Compatibility | Multivendor Compatible |
| DOM Support | Yes |
| Power Budget | 24 dB |
| Target transmission distance | Single-mode fiber: 40 km |
| Supported Protocols | Ethernet, SONET/SDH, Fiber Channel, OTN |
| Transmission rate | 10Gbit/s |
| Maximum Tx optical power | 4.0 dBm |
| Minimum extinction ratio | 3.0 dB |
