CE8850-64CQ-EI 64-Port 100GE QSFP28 2*AC Power Module 3*FAN Box Port-Side Intake

CE8850-64CQ-EI  64-Port 100GE QSFP28 2*AC Power Module 3*FAN Box Port-Side Intake
CE8850-64CQ-EI  64-Port 100GE QSFP28 2*AC Power Module 3*FAN Box Port-Side Intake CE8850-64CQ-EI  64-Port 100GE QSFP28 2*AC Power Module 3*FAN Box Port-Side Intake CE8850-64CQ-EI  64-Port 100GE QSFP28 2*AC Power Module 3*FAN Box Port-Side Intake CE8850-64CQ-EI  64-Port 100GE QSFP28 2*AC Power Module 3*FAN Box Port-Side Intake CE8850-64CQ-EI  64-Port 100GE QSFP28 2*AC Power Module 3*FAN Box Port-Side Intake CE8850-64CQ-EI  64-Port 100GE QSFP28 2*AC Power Module 3*FAN Box Port-Side Intake

Large Image :  CE8850-64CQ-EI 64-Port 100GE QSFP28 2*AC Power Module 3*FAN Box Port-Side Intake

Product Details:
Place of Origin: China
Brand Name: Huawei
Certification: CE
Model Number: CE8850-64CQ-EI

CE8850-64CQ-EI 64-Port 100GE QSFP28 2*AC Power Module 3*FAN Box Port-Side Intake

Description
Model: CE8850-64CQ-EI Processor: 1.5 GHz, Eight-core
DRAM Memory: 4 GB NOR Flash: 32 MB
Power Source Type: DC Dimensions: 3.47 In. X 17.4 In. X 23.6 In.
Weight: 22.2 Kg Condition: Brand New Sealed
Warranty: 1 Year Lead Time: 2-3 Days
Highlight:

64-Port Huawei Network Switches

,

QSFP28 2*AC Power Module

,

CE8850-64CQ-EI

CE8850-64CQ-EI  64-Port 100GE QSFP28 2*AC Power Module 3*FAN Box Port-Side Intake 0CE8850-64CQ-EI  64-Port 100GE QSFP28 2*AC Power Module 3*FAN Box Port-Side Intake 1

Physical Specifications

Dimensions (H x W x D): 88.1 mm x 442.0 mm x 600.0 mm (3.47 in. x 17.4 in. x 23.6 in.)
Weight (with two power modules and three fan modules, calculated based on the heaviest model if multiple models are supported): 22.2 kg

Temperature

Operating temperature: 0°C to 40°C (32°F to 104°F) at altitude of 0-1800 m (0-5906 ft.)
Storage temperature: -40°C to +70°C (-40°F to +158°F)
Relative humidity : 5% RH to 95% RH, noncondensing
Altitude : < 5000 m (16404 ft.)
Noise (sound pressure, 27°C) : Back-to-front airflow: < 64 dBA, Front-to-back airflow: < 64 dBA
Power source type : AC/DC/high-voltage DC

AC power input

Rated input voltage range: 100 V AC to 130 V AC/200 V AC to 240 V AC, 50/60 Hz
Maximum input voltage range: 90 V AC to 290 V AC, 47 Hz to 63 Hz

DC power input

Rated voltage range: -48 V DC to -60 V DC
Maximum voltage range: -38.4 V DC to -72 V DC

High-voltage DC power input

Rated voltage of 240 V high-voltage DC power input: 240 V DC
Maximum voltage range of 240 V high-voltage DC power input: 188 V DC to 290 V DC
Rated voltage range of 380 V high-voltage DC power input: 240 V DC to 380 V DC
Maximum voltage range of 380 V high-voltage DC power input: 188 V DC to 400 V DC

Rated input current

1200 W AC&240 V DC power module (PAC-1K2WA series): 10 A (100 V AC to 130 V AC)/8 A (200 V AC to 240 V AC)/8 A (240 V DC)
1200 W high-voltage DC power module (PHD-1K2WA series): 8 A (240 V DC to 380 V DC)
1200 W DC power (PDC-1K2WA series): 38 A (-48 V DC to -60 V DC)

Maximum power consumption : 965W

Typical power consumption

375 W (100% throughput, QSFP28 cables on 64 ports, double power modules)

Chassis heat dissipation

Maximum heat dissipation : 3293BTU/hr
Typical heat dissipation : 1280 BTU/hr (100% throughput, QSFP28 cables on 64 ports, double power modules)

Surge protection

Power module:
AC: 4 kV in common mode and 2.5 kV in differential mode
DC: 4 kV in common mode and 2 kV in differential mode

Technical specifications

Processor : 1.5 GHz, eight-core
DRAM Memory : 4GB
NOR Flash : 32MB

CE8850-64CQ-EI  64-Port 100GE QSFP28 2*AC Power Module 3*FAN Box Port-Side Intake 2
