Product Details:
|
| Product: | FS-224E-POE | Total Network Interfaces: | 24x GE RJ45 Ports And 4x GE SFP Ports |
|---|---|---|---|
| Power Over Ethernet (PoE) Ports: | 12 (802.3af/802.3at) | PoE Power Budget: | 180 W |
| Height X Depth X Width (mm): | 44 X 230 X 330 | Power Required: | 100–240V AC, 50–60 Hz |
| Operating Temperature: | 32–122°F (0–50°C) |
FS-224E-POE deliver a Secure, Simple, Scalable Ethernet solution with outstanding security, performance and manageability for threat conscious small to mid-sized businesses, distributed enterprises and branch offices.
FS-224E-POE specification |
|
| Hardware Specifications | |
| Total Network Interfaces | 24x GE RJ45 ports and 4x GE SFP ports |
| Dedicated Management 10/100 Port | 1 |
| RJ-45 Serial Console Port | 1 |
| Form Factor | 1 RU Rack Mount |
| Power over Ethernet (PoE) Ports | 12 (802.3af/802.3at) |
| PoE Power Budget | 180 W |
| Mean Time Between Failures | > 10 years |
| System Specifications | |
| Switching Capacity (Duplex) | 56 Gbps |
| Packets Per Second (Duplex) | 83 Mpps |
| MAC Address Storage | 16 K |
| Network Latency | < 1µs |
| VLANs Supported | 4 K |
| Link Aggregation Group Size | 8 |
| Total Link Aggregation Groups | Up to number of ports |
| Packet Buffers | 1.5 MB |
| DRAM | 512 MB |
| FLASH | 128 MB |
| Dimensions | |
| Height x Depth x Width (inches) | 1.73 x 9 x 12.99 |
| Height x Depth x Width (mm) | 44 x 230 x 330 |
| Power | |
| Power Required | 100–240V AC, 50–60 Hz |
| Power Supply | AC Built in |
| Redundant Power | Optional FRPS-740 |
| Power Consumption (Average / Maximum) | 220.18 W / 223.57 W |
| Heat Dissipation | 74.29554 BTU/h |
| Environment | |
| Operating Temperature | 32–122°F (0–50°C) |
| Storage Temperature | -4–158°F (-20–70°C) |
| Humidity | 10–90% non-condensing |
