Product Details:
|
| Part Number: | C9200-24PXG-A | Downlinks Total 10/100/1000 Or PoE+ Copper Ports: | 24 Ports Data |
|---|---|---|---|
| Uplink Configuration: | Modular Uplink Options | Fans: | FRU Redundant |
| Software: | Network Advantage | Stacking Bandwidth: | 160 Gbps |
| DRAM: | 4 GB | Flash: | 4 GB |
Catalyst 9200 series provides these highlights:
● Up to 48 ports of full Power over Ethernet Plus (PoE+) capability
● Resiliency with Field-Replaceable Units (FRU) and redundant power supply, fans, and modular uplinks
● Flexible downlink options with data or PoE+
● Operational efficiency with optional backplane stacking, supporting stacking bandwidth up to 160 Gbps
● UADP 2.0 Mini with integrated CPU offers customers optimized scale with better cost structure
● Enhanced security with AES-128 MACsec encryption, policy-based segmentation, and trustworthy systems
● Layer 3 capabilities, including OSPF, EIGRP, ISIS, RIP, and routed access
● Advanced network monitoring using Full Flexible NetFlow
● Cisco Software-Defined Access (SD-Access):
◦ Simplified operations and deployment with policy-based automation from edge to cloud managed with Cisco Identity Services Engine (ISE)
◦ Network assurance and improved resolution time through Cisco DNA Center™
● Plug and Play (PnP) enabled: A simple, secure, unified, and integrated offering to ease new branch or campus device rollouts or updates to an existing network
● Cisco IOS XE: A Common Licensing based operating system for the enterprise Cisco Catalyst 9000 product family with support for model-driven programmability and streaming telemetry
● ASIC with programmable pipeline and micro-engine capabilities, along with template-based, configurable allocation of Layer 2 and Layer 3 forwarding, Access Control Lists (ACLs), and Quality of Service (QoS) entries
| Product Name | Catalyst 9200 24-Port 8XMGIG PoE+ Netwo |
| Manufacturer Part Number | C9200-24PXG-E |
| Product Type | Ethernet Switch |
| Ethernet Technology | 10 Gigabit Ethernet |
| Number of Total Expansion Slots | 1 |
| Product Family | Catalyst 9200 |
| Stack Port | Yes |
| Media Type Supported | Twisted Pair |
| Total Number of Network Ports | 24 |
| Redundant Power Supply Supported | Yes |
| Energy Star | Yes |
| Expansion Slot Type | Network Interface Module (NIM) |
| Form Factor | Rack-mountable |
| Power Source | Power Supply |
| Layer Supported | 3 |
| Environmentally Friendly | Yes |
| Modular | Yes |
| Port / Expansion Slot Details | 16 x Gigabit Ethernet PoE+
8 x 10 Gigabit Ethernet PoE+ 1 x Expansion Slot |
| Country of Origin | Malaysia |
| Height | 1.7" |
| Width | 17.5" |
| Depth | 13.8" |
| Product Series | 9200 |
| Product Model | C9200-24PXG |
| Network Technology | 10GBase-T |
| Product Line | Catalyst |
| Limited Warranty | Lifetime |
| Stock Details | |
| Manufacturer | Cisco Systems |
| Manuf Part# | C9200-24PXG-E |
| Price | $3927.77 |
| Availability | Special Order |
