Product Details:
|
| Model: | ISR4351-V/K9 | Aggregate Throughput: | 200 Mbps To 400 Mbps |
|---|---|---|---|
| Default Memory Double-data-rate 3 (DDR3) Error-correction-code (ECC) DRAM (Combined Control/service: | 4 GB | Maximum Memory DDR3 ECC DRAM (Combined Control/services/data Planes): | 16 GB |
| Power-supply Options: | Internal: AC, DC, And PoE | Condition: | Brand New |
| Warranty: | 1 Year | Payment: | TT, Western Union, Paypal |
| Transportation: | DHL, Fedex, UPS | Shipping: | 5-7 Days |
Cisco ISR4351-V/K9 is ideally designed for the mid-size or even large enterprise branch environment, deliver advanced services and unprecdent level of WAN intelligence with VOIP features enabled.Scalability, High-performance, Network Services, Security and smart router is made to run multiple services.Advanced network services enable the branch to utilize the WAN intelligently is really what ISR4351/K9 all about.With feature like , Voice, AVC, performance routing (PfR), WAAS make this platform obviously more than a router, moreover, the Cisco Integrated Services Router 4351 include supporting OnePk, AppNav, making the platform easier to scale the network and application integration.
| Models | ISR4351-V/K9 | ISR4351/K9 |
| Description | Cisco ISR4351-V/K9 (3GE,3NIM,2SM,4G FLASH,4G DRAM,Voice Bundle) | Cisco ISR 4351 (3GE,3NIM,2SM,4G FLASH,4G DRAM,IP Base) |
| Aggregate Throughput | 200 Mbps to 400 Mbps | 200 Mbps to 400 Mbps |
|
Total onboard WAN or LAN 10/100/1000 ports |
3 | 3 |
| RJ-45-based ports | 3 | 3 |
| SFP-based ports | 3 | 3 |
| Enhanced service-module slots | 2 | 2 |
| NIM slots | 3 | 3 |
| Onboard ISC slot | 1 | 1 |
| Rack height | 2 | 2 |
ISR4351-V/K9 Specification |
|
| Description | Cisco ISR4351-V/K9 (3GE,3NIM,2SM,4G FLASH,4G DRAM,Voice Bundle) |
| Aggregate Throughput | 200 Mbps to 400 Mbps |
| Total onboard WAN or LAN 10/100/1000 ports | 3 |
| RJ-45-based ports | 3 |
| SFP-based ports | 3 |
| Enhanced service-module slots | 2 |
| Doublewide service-module slots | 1 (assumes no singlewide SM-X modules installed) |
| NIM slots | 3 |
| OIR (all I/O modules) | Yes |
| Onboard ISC slot | 1 |
|
Default memory double-data-rate 3 (DDR3) error-correction-code (ECC) DRAM (Combined control/services/data planes) |
4 GB |
| Maximum memory DDR3 ECC DRAM (Combined control/services/data planes) | 16 GB |
| Default memory DDR3 ECC DRAM (data plane) | NA |
| Maximum memory DDR3 ECC DRAM (data plane) | NA |
| Default memory DDR3 ECC DRAM (control/services plane) | NA |
| Maximum memory DDR3 ECC DRAM (control/services plane) | NA |
| Default flash memory | 4 GB |
| Maximum flash memory | 16 GB |
| External USB 2.0 slots (type A) | 2 |
| USB console port -type B mini (up to 115.2 kbps) | 1 |
| Serial console port - RJ45 (up to 115.2 kbps) | 1 |
|
Serial auxiliary port - RJ45 (up to 115.2 kbps) |
1 |
| Power-supply options | Internal: AC, DC, and PoE |
| Redundant power supply | N/A |
| AC input voltage | 100 to 240 VAC autoranging |
| AC input frequency | 47 to 63 Hz |
| AC input current range, AC power supply (maximum) | 7.1 to 3.0A |
| AC input surge current | 60 A peak and less than 12 Arms per half cycle |
| Typical power (no modules) (watts) | 48 |
| Maximum power with AC power supply (watts) | 430 |
| Maximum power with PoE power supply (platform only) (watts) | 990 |
| Maximum endpoint PoE power available from PoE power supply (watts) | 500 |
