OSX040N01 Specification
OSX040N01 Specifications |
|
| Product Model | OSX040N01 |
| Brand | Huawei |
| Form factor | SFP+ |
| Data Rate | 10G |
| Transmission Medium | Single-mode |
| Wavelength | 1550nm |
| DDM options | Supported |
| Connector Type | LC |
| Operating Temperature | 0°C to 70°C (32°F to 158°F) |
| Diagnostics Monitoring | Supported |
| Optical Interface | Duplex LC |
| Compatibility | Multivendor Compatible |
| DOM Support | Yes |
| Power Budget | 24 dB |
| Target transmission distance | Single-mode fiber: 40 km |
| Supported Protocols | Ethernet, SONET/SDH, Fiber Channel, OTN |
| Transmission rate | 10Gbit/s |
| Maximum Tx optical power | 4.0 dBm |
| Minimum extinction ratio | 3.0 dB |
