Product Details:
|
| Product Code: | S-SFP-GE-LH40-SM1310 | Transceiver Form Factor: | ESFP |
|---|---|---|---|
| Transmission Speed: | 1 Gbit/s | Connector Type: | LC |
| Net Dimension: | 110mm X 70mm X 37mm | Condition: | Original New |
| Warranty: | 1 Year | Shipping: | DHL, UPS, Fedex |
| Payment: | TT, Western Union, Paypal |
Optcore’s OSP1250-3140DCR-HW is a high performance and cost effective small form factor pluggable (SFP) transceiver for 1000BASE-EX Gigabit Ethernet and 1G Fiber Channel application. It is fully comply with the SFP Multi-Sourcing Agreement (MSA) and can be used on the MSA compliant networking equipment.
• Functionally identical to HW S-SFP-GE-LH40-SM1310 1000BASE-EX SFP module
• Far less price than OEM transceiver
• Built-in digital diagnostic monitoring interface for real-time monitoring of operating parameters
• Single 3.3V power supply
• Low power dissipation
• ROHS compliant and Lead-Free
S-SFP-GE-LH40-SM1310 Specification |
|
| Transceiver form factor | eSFP |
| Transmission speed | 1 Gbit/s |
| Center wavelength (nm) | 1310 |
| Standard compliance | 1000base-LX/LH |
| Connector type | LC |
| Applicable cable and maximum transmission distance | Single-mode fiber: 40 km |
| Transmit power (dBm) | -5.0 to 0 |
| Maximum receiver sensitivity (dBm) | -23 |
| Overload power (dBm) | -3.0 |
| Extinction ratio (dB) | 9 |
| Operating temperature | 0°C to 70°C (32°F to 158°F) |
| Net Dimension(D x W x H mm) | 110 x 70 x 37 |
