Product Details:
|
| Condition: | Original New | Warranty: | 1 Year |
|---|---|---|---|
| Lead Time: | 1-2 Days | Application: | Indoor |
| Type: | Core | MOQ: | 1 PCS |
| Brand: | NVIDIA | Product Status: | Stock |
| Highlight: | Original New NVIDIA A100 Tensor Core GPU,1 Year Warranty A100 GPU,1-2 Days Lead Time Tensor Core GPU |
||
| Product Code | C9300-24T-E | C9300-24P-A |
|---|---|---|
| Product Description | Catalyst 9300 24-port data only, Network Essentials | Catalyst 9300 24-port PoE+, Network Advantage |
| Total 10/100/1000 or Multigigabit copper ports | 24 | 24 POE+ |
| Default AC power supply | 350W AC | 715W AC |
| Available PoE power | -- | 445W |
| Dimensions (H x W x D) | 1.73 x 17.5 x 17.5 Inches | 1.73 x 17.5 x 17.5 Inches |
| Weight | 16.33 Pounds | 16.33 Pounds |
| Specification | Details |
|---|---|
| Part Number | C9300-24T-E |
| Product Description | Catalyst 9300 24-port data only, Network Essentials |
| Total 10/100/1000 or Multigigabit copper ports | 24 |
| Default AC power supply | 350W AC |
| Available PoE power | -- |
| Cisco StackWise-480 | Yes |
| Cisco StackPower | Yes |
| Default power supply | PWR-C1-350WAC-P/2 |
| Switching capacity | 208 Gbps on 24-port Gigabit Ethernet model |
| Stacking bandwidth | 480 Gbps |
| Total number of MAC addresses | 32,000 |
| Total number of IPv4 routes (ARP plus learned routes) | 32,000 (24,000 direct routes and 8000 indirect routes) |
| IPv4 routing entries | 32,000 |
| IPv6 routing entries | 16,000 |
| Multicast routing scale | 8000 |
| QoS scale entries | 5120 |
| ACL scale entries | 5120 |
| Packet buffer per SKU | 16 MB buffer for 24- or 48-port Gigabit Ethernet models |
| FNF entries | 64,000 flow on 24- and 48-port Gigabit Ethernet models |
| DRAM | 8 GB |
| Flash | 16 GB |
| VLAN IDs | 4000 |
| Total Switched Virtual Interfaces (SVIs) | 2000 |
| Jumbo frames | 9198 bytes |
| Total routed ports per 9300 Series stack | 208 |
| Wireless bandwidth per switch | Up to 48 Gbps on 24-port Gigabit Ethernet model |
| Forwarding rate | 154.76 Mpps |
| Dimensions (H x W x D) | 1.73 x 17.5 x 17.5 Inches |
| Weight | 16.33 Pounds |
| Mean time between failures (hours) | 299,000 |
| Specification | A100 80GB PCIe | A100 80GB SXM |
|---|---|---|
| FP64 | 9.7 TFLOPS | |
| FP64 Tensor Core | 19.5 TFLOPS | |
| FP32 | 19.5 TFLOPS | |
| Tensor Float 32 (TF32) | 156 TFLOPS | 312 TFLOPS* |
| BFLOAT16 Tensor Core | 312 TFLOPS | 624 TFLOPS* |
| FP16 Tensor Core | 312 TFLOPS | 624 TFLOPS* |
| INT8 Tensor Core | 624 TOPS | 1248 TOPS* |
| GPU Memory | 80GB HBM2e | 80GB HBM2e |
| GPU Memory Bandwidth | 1,935 GB/s | 2,039 GB/s |
| Max Thermal Design Power (TDP) | 300W | 400W *** |
| Multi-Instance GPU | Up to 7 MIGs @ 10GB | Up to 7 MIGs @ 10GB |
| Form Factor | PCIe Dual-slot air-cooled or single-slot liquid-cooled | SXM |
| Interconnect | NVIDIA® NVLink® Bridge for 2 GPUs: 600 GB/s ** PCIe Gen4: 64 GB/s | NVLink: 600 GB/s PCIe Gen4: 64 GB/s |
| Server Options | Partner and NVIDIA-Certified Systems™ with 1-8 GPUs | NVIDIA HGX™ A100-Partner and NVIDIA-Certified Systems with 4,8, or 16 GPUs NVIDIA DGX™ A100 with 8 GPUs |
