Product Details:
|
| Brand Name: | Huawei Module | Product Code: | OMXD30000 |
|---|---|---|---|
| Transceiver Form Factor: | SFP+ | Product Line: | Networking |
| Transmission Speed: | 10 Gbit/s | Connector Type: | LC |
| MOQ: | 1PC | Warranty: | 1 Year |
| High Light: | Huawei OMXD30000,10GBASE-ILR Optical Transceiver Module,Single Mode Optical SFP Module |
||
OMXD30000
Huawei OMXD30000 is a 10GBASE-iLR Optical Transceiver. It’s a Single-mode Module.
| Transceiver form factor | SFP+ |
| Transmission speed | 10 Gbit/s |
| Center wavelength (nm) | 1310 |
| Standard compliance | 10GBASE-iLR |
| Connector type | LC |
| Applicable cable and maximum transmission distance | Single-mode fiber: 1.4 km |
| Transmit power (dBm) | -8.2 to +0.5 |
| Maximum receiver sensitivity (dBm) | -14.4 |
| Overload power (dBm) | 0.5 |
| Extinction ratio (dB) | 3.5 |
| Operating temperature | -40°C to +85°C (-40°F to +185°F) |
